Rare behind the scenes video of Iranian Air Force Sukhoi Su-24 Fencer operations February 19, 2012

Posted by David Cenciotti in Iran.
Tags: , , ,
4 comments

The following interesting video shows daily operations at the Islamic Republic of Iran Air Force Sukhoi Su-24 Fencer, belonging to the 72nd Bomber Squadron at TAB-7 in Shiraz.

Mission briefing, dress rooms, flying clothing as well as a taxi ride by a journalist in the Fencer (this explains why he doesn’t wear a flight suit). Also cockpit images during buddy refueling and air-to-air footage of a KH-29L (AS-14 “Kedge” in NATO designation) air-to-surface laser-guided missile test fire.

A rare and quite long (unfortunately in original language) “behind the scenes” of one of the most interesting Iranian combat planes.

Related articles

F-14s, in-flight emergencies and arrested landings. Top Gun? No, an Iranian TV series February 17, 2012

Posted by David Cenciotti in Iran.
Tags: , , , ,
7 comments

It is very well known that, more or less one year ago China tried to pass off Top Gun as air force footage but did you know there was also a mini-Top Gun made in Iran?

If not, have a look at the following video.

An IRIAF (Islamic Republic of Iran Air Force) F-14, part of a flight of four, suffers a hydraulic failure and is forced to perform a successful emergency landing using the runway arresting system.

Screenplay aside, the video is extremely interesting as it shows the rare Tehran’s Tomcats, one of those can be seen engaging the cable with the tailhook. Noteworthy, some of the radio comms are in English language (with Persian subtitles).

According to the information provided by the user who uploaded it on Youtube, the footage is from the Iranian TV series Shoghe Parvaz.

Thanks to Al Clark for the heads up.

Related articles

Iranian indigenous aircraft and micro-drones: Mach 2.5 stealth plane and scale models (with no military significance) February 11, 2012

Posted by Richard Clements in Drones, Iran.
Tags: , , , , , , ,
7 comments

It is no secret that the sanctions held against Iran are crippling the influx of military equipment forcing Iran to make its own aircraft to replace ageing U.S. types as the F-4 and the F-14 recently seen escorting the Russian Knights display team.

In 2002, the idea of a light weight stealth fighter came to light when a model surfaced during an air industry exhibition. It showed a single seat, single engine fighter with outward canted twin vertical stabilisers. It took Iranian news footage in 2004 for the first full size and seemingly working example to reach the public domain.

Although there are rumours Russian experts from both Sukoi and Mikoyan and possibly Yakolev were also involved in its development, which would explain its striking resemblance to the forward fuselage of the Yak-130, it had been developed by the Students and scientists of the Aviation department of the Malek Ashtar University and reported to have made its maiden flight some time in 2004 using an Iranian version of the Klimov RD-33 engine.

The news footage showed a twin seat example with a semi-matt black fuselage suggesting that it could have been made from Radar Absorbing Materials, and from certain angles, the aircraft looks like a two seat F-35. Even if it has never been ratified, the use of radar absorbing materials are said to significantly reduce the Radar Cross Section.

The light fighter bomber has been named “Shafagh-2″ or “Aurora” and is said to have a special twisting ability that gives it better manoeuvrability and roll rate. This may be one of those times where things get lost in translation and the twisting might refer to thrust vectoring (!) rather than roll rate.

The Shafagh is designed as a single seat or twin seat multi role fighter; it has seven hard points, three under each wing and one centreline station and can carry a mixed Air-to-Air load or Air-to-Ground weapons.  The use of pylons under the wings would surely hinder any stealth capability the aircraft has, although the level of stealthiness in comparison to that of the F-22 Raptor or B-2 Spirit should be somewhat less.

The aircraft is certainly real and has flown; it’s unknown in what capacity it has flown but certainly has never entered service. Its last known activity was in 2008 and it should have remained an unfinished project.

Even if some performance data seem to be quite strange or at least hopeful, its reported figures are of a climb rate of 21650 fpm, a service ceiling of 55,000ft and a top speed of Mach 2.5.

Image credit: iranmilitaryforum.com

Micro-drones

Since the U.S. stealthy RQ-170 drone was captured, Tehran has been using the media to display its capability to reverse engineer or build its own drones.

However, some of them seems to be modified radiocontrolled models rather than real UAS (Unmanned Aerial Systems). Anyway, those made by the students at the Nasr Toosi Technical University, are believed to give a hint at where Iranians are in their Micro-UAV development.

For instance, one of the University’s micro-drones is a model helicopter modified to carry a small video camera. As the images show, the tail boom and the landing skids have the word “ALIGN” written on them in English. A quick visit to Google brings up the manufacturer as ALIGN-TREX, a British Radio controlled helicopter specialist with an online shop, while the camera set up suspiciously looks like a ‘SONY’ handycam again commercially available.

The intended use of this device is quite hard to understand. The camera must have an internal memory as the model does not look to have  a transmitter to send the real time images back to a receiver/base station (that would also need a power supply which is not visible). This discounts a urban battlespace ‘eye in the sky’ for a normal drone used to record images to view at a later date.

The second model has a twin tail boom, a size that would suggest a greater payload capacity and perhaps a real time video transmission capability.

The third model (UAV) looks more like a classical drone. Grey in colour, a rounded nose and what looks like a moveable nose area with a small camera able to move up and down in the slot giving a 180 degree field of view, the drone seems to be powered by an electric motor powering a push propeller.

Image credit: www.yjcphotos.ir

As said, just technology demonstrators that don’t really show anything of military significance.

Written with The Aviationist’s Editor David Cenciotti.

Related articles

That’s a low level strike: Iranian Air Force F-4 Phantom February 9, 2012

Posted by Richard Clements in Iran, Military Aviation.
Tags: , , , , ,
1 comment so far

This series of photos found on the internet, shows what appears to be an ultra low level attack on a unknown location probably dating back to at least 20 years ago.

The silhouette is clearly that of an Islamic Republic of Iran Air Force F-4 Phantom striking Iraqi forces during the Iran-Iraq war (1980-1988). Although some believe that the images were taken from an RF-4, the interesting thing that stands out from these amazing photos is the extreme low level of the attack.

Even though the images were not taken downtown, generally speaking, flying low level was paramount to prevent being detected and hit by the air defenses protecting Baghdad: after the war, Iranian pilots recalled flying as low as 20 meters above the ground level during their strike missions. To such an extent that power cables on the outskirts or Iraq’s capital town became a significant risk for Tehran’s pilots.

Richard Clements for TheAviationist.com

Image credit: Iranian internet

Related articles

Some (rusty) Iranian Mig-29s on display at Tabriz airbase in new images released by IRNA news agency February 5, 2012

Posted by David Cenciotti in Iran.
Tags: , , , , , ,
7 comments

IRNA (Islamic Republic News Agency) has just released some quite interesting pictures of an exhibition of IRIAF planes and equipment that took place at Tabriz, in northwest of Iran.

Among the images made public by the news agency, some depict some (quite “rusty”, or at least dirty) Mig-29s, along with F-5Es and “Saeqeh” (Thunder) an indigenously modified version of the American F-5 Tiger, whose twin tails and blue colour are loosely reminiscent of the Blue Angels.

Generally speaking, the flying F-14s and F-4s recently exposed in the Russian Knights pictures taken during the return trip of the team from Bahrain International Air Show seemed to be in better conditions than these Mig-29s: at least one of the Fulcrum on display is unserviceable (it lacks both engines).

Image credit: IRNA news agency

Related articles

Russian Sukhoi Su-27s + Iranian F-14s + Iranian F-4s = the most exotic formation ever! January 31, 2012

Posted by David Cenciotti in Iran, Military Aviation.
Tags: , , , , , , , ,
12 comments

Although some pictures of this unbelievable formation have been already published on aviation website, the Russian Knights, Russian Air Force aerobatic display team has released some more images of the weird formation of Russian Su-27s (with the supporting Il-76), IRIAF (Islamic Republic of Iran Air Force) F-14 Tomcats and F-4 Phantoms taken during the ferry flight that took the the team home from the Bahrain International Air Show 2012.

A unique opportunity to see some really “exotic” planes flying in (quite loose) formation over Iran, in a quite tense period.

Image credit: Sergei Shcheglov Russian Knights via http://sergeydolya.livejournal.com/423952.html (visit this site for more pictures)

Related articles

Another day, another Iranian drone. Tehran reveals the new “A1″ UAV. January 30, 2012

Posted by Richard Clements in Drones, Iran.
Tags: , , , , , , , , ,
4 comments

On Jan. 30, Iran has announced the development of a new UAV (Unmanned Aerial Vehicle) called the “A1″. According to the information released so far, the new drone allegedly has a service ceiling of 10,000 feet, an endurance of two hours and can carry up to a 11lbs (5kg) payload. Furthermore, it has an engine running on hi-octane gas/oil mix (2 stroke engine??) with a 2 blade pusher propeller and can be either launched from a ramp attached to the bed of a truck or ship-launched from rocket launchers.

These “features” seem to suggest that the new drone  is another variant of the Ababil indigenous UAV family, which already includes the Ababil-5,  used as a medium range surveillance platform, and the Ababil-T, a short to medium range UCAV with offensive capabilities.

Image credit: PressTV

Press TV website which broke the news also mentions a –B and a –S version but does not disclose what the purposes of these are.

It was an Ababil-T drone, allegedly launched from within Lebanon and sported Hezbollah markings, that was shot down in 2006 by an Israeli Air Force F-16 using a Rafael Python 5, about 5 nautical miles off Israel’s coast.

Ababil-T (credit: IDF)

The launching of the new drone is a further evidence of a blooming indigenous UAV program which has similar beginnings to that of the Israeli UAV program, started many years ago to develop drones for artillery spotting and battlefield overwatch as well as decoys for SAM sites (they are used to personify manned assets and spur a reaction by the SAM site that can be then attacked by other SEAD assets).

Although the significance of Iran’s UAV program remains unclear (especially if we consider the claims about the prodigious performance of some drones that are nothing more than scale models), it’s once again interesting to notice how the Iranian government use the local media to trickle out information on new systems being developed by Tehran.

The Aviationist will monitor further developments as and when they arise.

Written with The Aviationist’s Editor David Cenciotti

U.S. aircraft carriers face Iranian stealth subs in the Persian Gulf. And remote controlled ones too… January 19, 2012

Posted by David Cenciotti in Aircraft Carriers, Iran.
Tags: , , , , , , , , , , ,
13 comments

Although the U.S. Navy has just rescued sailors of an Iranian boat in distress for the third time in 10 days, Tehran doesn’t seem to appreciate the aid that the American warships are giving to Iranian civilian mariners in the Persian Gulf.

In an interview with the Fars News Agency, Rear Adm. Farhad Amiri said that Iran’s ordinary submarines, covered with coatings that make them stealth, since “do not allow sound to travel through them and do not reflect waves sent by sonar systems”, could by the worst threat U.S. aircraft carriers will have to face next time they cross the Strait of Hormuz.

Since they American flattops can’t track them, Iranian submarines have acquired the ability to hide at the proper depth and “when the submarine lies on the sea bed, it can easily target an aircraft carrier that is passing nearby,” Amiri said.

Being one of the most powerful tools in the hands of the U.S., aircraft carriers are one of the most ambitious targets of any anti-American country. That’s why they are also some of the most heavily defended assets which does not travel alone (as done by the Chinese trainer Varyag) but alongside a Strike Group (once known as Battle Group) including ships, supporting vessels and a nuclear submarine, whose task is, among the others, to defend the flattops from underwater attacks.

So, although I’m unable to determine whether the threat posed by the Iranian subs is real or not (actually unable to say whether the subs are really stealth because they don’t even exist…), I would still bet on the Carrier Strike Group. Especially considering the usual claims made by the regime in the last years.

According to Mehr News agency, in a couple of month Iran plans to launch new 500-ton submarine Fateh (Conqueror) submarine, whereas Iranian researchers have built a new 3-kg smart remote-control sub, with a submerged speed of 19 kts, capable to carry out surveillance missions for…one meter (I hope there was a problem with the translation otherwise this would remind me of the surveillance drone that resembled a radio-controlled scale model more than a modern drone).

Never seen before pictures: Iran’s (blue-colored) Sayyad-2 anti-aircraft missile exposed January 4, 2012

Posted by David Cenciotti in Iran, Military Aviation.
Tags: , , , , , , , , , ,
3 comments

Since a U.S. RQ-170 Sentinel drone was captured in Iran on Dec. 4, 2011, I’ve been a frequent visitor of Iranian news agencies, State TV and newspapers websites.

This semi-official sources have provided an interesting variety of images and videos about Iran’s military. Not only the famous photographs of the “Beast of Kandahar” and the doctored video allegedly showing the American drone landing at an Iranian airbase, but also the footage of the U.S. aircraft carrier Stennis cruising near the Strait of Hormuz, and a funny model of a Hondajet plane advertised as Tehran’s new surveillance drone.

Today, what I’ve found on the IRG website is not a photoshopped image, or a video whose authenticity is debatable, but some really interesting and genuine (at least at first glance) photographs of the Sayyad-2 anti-aircraft missile system at work.

The Sayyad-2 is an improved (and probably outwardly much similar, if not identical) version of the Sayyad-1 missile, an Iranian indigenized system of a Chinese development of the Russian S-75 (SA-2 “Guideline” in NATO designation – yes, the SAM system that brought down Francis Gary Powers and his U-2 in 1960).

The existence of this surface-to-air missile system, that according to the most authoritative sources also integrates North Korean technology, was made public in April 2011, but the one just published are, to my knowledge, the first images of the Sayyad 2 being test-fired available on the web.

According to the IRG website, the photographs were taken during  “Great Prophet 6″, an exercise that took place at the end of April, and included the test launching of the Shahab-1, Shahab-2 and Shahab-3 and Zelzal missiles.

Since then, the Sayyad has been deployed in all air-defense units across Iran. Hence, it is one of the SAM systems any U.S. or Israeli plane (either stealth or not) will have to face in case of future attack (provided that some sort of covert war on Tehran nuclear program has not started yet).

As said, the latest Iranian SAM system is a modified version of the Sayyad-1, a two-staged air defense missile capable to destroy targets with a low Radar Cross Section (RCS) flying at low, medium and very high altitude (with a claimed ceiling of 80,000 feet).

According to the data contained in a FARS news agency article published last year, the Sayyad-2 travels at 3,600 km/h (2,500 mph), has a range of 80-100 km, includes ECCM (Electronic Counter-Counter Measures) equipment and carries a 200-kilogram warhead.

And, as images show, it is colored in light-blue, a bit flashy/naive for a SAM missile that should try to remain unvisible for as long as possible.

By the way, according to the EXIF data, pictures were taken on Apr. 15 and Jun. 6, 2011.

Image source: sepahnews.com

Once in a while a genuine video from Iran: Iranian Air Force F-5 nose-gear-up landing January 3, 2012

Posted by David Cenciotti in Iran, Military Aviation.
Tags: , , , , , , , , , , , , ,
3 comments

In the last few weeks, beginning with the saga of the captured US stealthy RQ-170 drone and ending with the crisis in the Strait of Hormuz, with the alleged video of the U.S. aircraft carrier Stennis taken from an Iranian Fokker 27, I’ve often discussed about the authenticity of the footage released by the Iranian State TV or news agency, with the readers of this blog.

In the past, the Iranian propaganda machine has used doctored videos and fake images to spread its messages and this is the reason why many are doubtful each time new images showing Iran’s military achievement surface.

However, the one I’m posting below was just uploaded on Youtube (date is Jan. 1, 2012) and looks like it is authentic.

It shows an Islamic Republic of Iran Air Force (IRIAF) F-5E performing a nose-gear-up landing at Dezful airbase also known as Vahdati Air Base, in southwest Iran.

The aircraft comes to a stop thatnks to the dragchute and, later, we see the pilot unhurt near its plane.

Actually, we can’t be sure whether the nose gear failed to come down or it collapsed after landing: the fact that someone was filming it (from a dangerous position) suggests the emergency was known before the aircraft landed, still, ground personnel seems to be unprepared to the management of the emergency, with people and cars initially rushing towards the plane and then coming back.

Dealing with the news, on Jan. 2, the IRNA news agency has published another picture, this time depicting the coast-to-sea long-range missile, named the Qader (Capable), with a range of 200 km and capable to target destroyers and battleships.

Delivered to the Navy in September 2011, the Qader is believed to be the most powerful missile of the Iranian Navy.

A short-range Nasr (Victory) cruise missile with the capability to destroy large vessels, and a surface-to-surface Nour (Light) “ultra-advanced surface-to-surface missile” were fired by the Iranian naval forces in the last phase of the Exercise Velayat-90, as well as a surface-to-air medium-range smart missile, named the Mehrab (Altar), equipped with anti-radar and anti-jamming systems.

To be honest, mainstream media have all broadcast the same image, with different captions, so my guess is that the one in this picture is the Qader, even if it might be a Nour (as affirmed by the IRNA website…wasn’t the Nour a surface-to-surface missile?).
