This Outstanding Footage Celebrates Retirement of F-4EJ “Kai” Phantom II 47-8333 “Tora-San” After 44 Years

A very special Japan Air Self Defense Force F-4EJ Phantom.

On Apr. 11, 2018, Japan’s Air Force retired one its F-4EJ “Kai” Phantom II jets: the example serialled 47-8333/”333″ assigned to the 302nd Tactical Fighter Squadron of the 7th Air Wing of the Japanese Air Self-Defense Force based at Hyakuri Air Base in the Ibaraki Prefecture of Japan.

The aircraft served with the JASDF for 44 years. Originally an F-4EJ, it was upgraded to the “Kai” (“extra”) variant during the mid ’80s, as part of a modernization program that included, among the other things, the installation of a new AN/APG-66J pulse-Doppler radar, a new central computer, a Kaiser HUD (Head Up Display), an AN/APZ-79 IFF system, as well as the ability to carry an AN/ALQ-131 advanced multimode electronic countermeasures pod and to launch the AIM-7E/F Sparrow and the AIM-9L/P Sidewinder AAMs (air-to-air missiles).

According to one of our readers who pointed us to the video below, the aircraft 47-8333, usually called “Triple 3”, was often called “Trouble 3” as a consequence of some issues it suffered. On the very last day of activity before the retirement, the splitter vane of the “333” sported the text “Tora-san, Thank you”: indeed, this aircraft got the name Tora-san, the loveable character of the Japanese movie series “Otoko wa Tsurai yo (It’s tough being a man)”, the world’s longest running film series.

H/T Akihiro Kanai for sending this over to us. Top image: screenshot from 1-300 Youtube video.

Lockheed Martin to Propose 5th Gen F-22/F-35 Hybrid to Japan.

New Proposed Stealth Hybrid Fighter to Expand Japanese Fighter Capability. Re-opening the F-22 Production Line might be an option too.

Late Friday, April 20, Reuters journalists Tim Kelly and Nobuhiro Kubo reported that Lockheed Martin will propose a new 5th generation low-observable (stealth) combat aircraft to Japan. According to Kelly and Kubo’s article, the two sources who provided the information to Reuters have direct knowledge of the upcoming proposal.

According to the sources with direct knowledge of the program quoted in the April 20 Reuters story, “Lockheed has discussed the idea with Japanese defense ministry officials and will make a formal proposal in response to a Japanese request for information (RFI) after it receives permission from the U.S. government to offer the sensitive military technology.”

Reuters quoted one of the two unnamed sources as telling them, “The proposed aircraft would combine the F-22 and F-35 and could be superior to both of them.”

The F-22 Raptor is only used by the United States Air Force and is not exported because some of its capabilities remain a national security asset. The F-35 Joint Strike Fighter was originally conceived as an export project to provide cost sharing and capability commonality between partner nations as a force multiplier.

The new Japanese aircraft to be proposed by Lockheed Martin will be an air superiority aircraft with a similar role to the F-22 Raptor.

The Japanese rolled out their first domestically built F-35A Joint Strike Fighter from Mitsubishi Heavy Industries Komaki South F-35 Final Assembly and Check Out (FACO) facility on June 5, 2017. Lockheed Martin built four of the first Japanese F-35s in the U.S. and delivered them to Japan. The remaining 38 of 42 total F-35As Japan has planned will be built at the Mitsubishi Heavy Industries Komaki South facility. Mitsubishi was the builder of the famous A6M Zero fighter used in WWII.

The Reuters report about the new Lockheed Martin proposal is set alongside the existing Japanese Mitsubishi X-2 Shinshin design originally designated the ATD-X for “Advanced Technology Demonstrator – X”. This aircraft bears a strong resemblance to the Lockheed Martin F-22 Raptor, using the same basic overall configuration. The ATD-X/X-2 Shinshin is a two-seat experimental aircraft whereas the F-22 and F-35 are only single seat aircraft. Only one X-2 Shinshin has been produced by Japan as a technology testbed. It first flew on April 22, 2016.

The reports of the new upcoming proposal from Lockheed Martin could suggest that Japan is considering abandoning its own indigenous fifth generation air superiority development program in favor of a design from another country. One stipulation reported by the source who spoke to Reuters was that any new proposed aircraft from outside Japan must have Japanese engines, radar and other components. This suggests that an additional, new vendor like Lockheed Martin may be primarily an airframe supplier.

The Reuters report did quote the Japanese Ministry of Defense as saying, “We are considering domestic development, joint development and the possibility of improving existing aircraft performance, but we have not yet come to any decision.”

There are a number of motives for Japan to consider a ground-up aircraft development for its own Gen 5+ aircraft. Perhaps the most compelling reason to consider a new direction are the lessons learned from the massive development processes for both the U.S. F-22 Raptor and the F-35 Lighting II Joint Strike Fighter.

Both the F-22 and F-35 programs were expensive and groundbreaking in terms of leading the Gen 5 integration of combat aircraft into an air force. The attendant costs of those programs can be amortized and benefitted from in new development aircraft. The implication is they could be both better and cheaper.

Another reason for the shift in interest to a new Gen5+ direction for Japan’s next air superiority fighter is China. A March 15, 2018 article by Kyle Mizokami in Popular Mechanics quoted Chinese aircraft developer Yang Wei, deputy director of advanced of science and technology at Aviation Industry Corp of China and member of the Chinese Academy of Sciences, as saying, “We are not complacent about what we have achieved. We will develop the J-20 into a large family and keep strengthening its information-processing and intelligent capacities. At the same time, we will think about our next-generation combat plane to meet the nation’s future requirements.”

China has also been active in expanding its export market for tactical aircraft, although advanced aircraft like the J-20s are likely to remain exclusively Chinese. Japan may look to co-develop a new aircraft that could possibly have limited export appeal in the region, provided the buy-in were lower than F-35.

Japan wants Lockheed Martin to propose a new stealth air superiority fighter. (Photo: Tom Demerly/TheAviationist.com)

The costs of re-opening the F-22 production line, or even some version of it, have been generally regarded as prohibitive. However, Tyler Rogoway at The War Zone has long been advocating a sale of Raptors to Japan. In the 2016 story “Just Allow The F-22 To Be Exported To Japan Already“. Here’s a short excerpt from Tyler’s latest article on this subject (but I strongly recommend reading the whole story):

“Although Japan has put forward notional Raptor-like designs, what they could also be talking about here is merging the higher kinematic performance and low-observability of the F-22 with the F-35’s smarter attributes—including updated avionics, mission computers, and sensors—as well as new lower-maintenance skin coatings.

[…]

That cost [to put an updated F-22 back into production] may be too high for the USAF to stomach, but for Japan, it’s highly unlikely they will be able to field something superior to an updated F-22 for anywhere near less. It’s also likely that once the U.S.-specific politics of putting the Raptor back into production are removed from the equation, the cost of doing so would drop.

But if Japan is willing to buy an updated Raptor instead of developing a near identical but still unique design, clearly doing so would present a mutually beneficial opportunity. If the U.S. would become a minority stakeholder in an F-22 production line restart of sorts, with the intent on buying a number of airframes to bolster the USAF’s undersized and cherished F-22 fleet, then the opportunity could work out for both parties.

[…]

We will watch how this story develops closely, but if the Pentagon was smart, they would embrace an upgraded F-22 restart with Japan, and if Tokyo is willing to foot the majority of the bill for doing so, the USAF would be nuts not to take advantage of it. “

Indeed, this cost-sharing strategy between the U.S. and Japan would be a significant win-win, especially with the U.S. need for more F-22s. Let’s see what happens.

Top image: A wind tunnel model of Japan’s indigenous gen 5 stealth air superiority fighter. (Photo: Tom Demerly/TheAviationist.com)

U.S. Approves Possible Sale of 34 Lockheed F-35s to Belgium; Japan Deploying First F-35 to Misawa; India Allegedly Enters Conversation.

Based on latest news, it may have been a good weekend for the F-35.

The U.S. State Department issued a statement late Friday confirming it has approved the possible sale of 34 Lockheed F-35 Lightning II Joint Strike Fighters to Belgium. The authorization permitting the sale of advanced defense technology is a key step toward completing the actual purchase, quoted to be worth up to “$6.53 billion USD”. The proposed contract with Lockheed Martin, builder of the F-35 Joint Strike Fighter, would include 38 new Pratt & Whitney advanced F-135 jet engines that power the F-35.

Based on reports Belgium would potentially buy the F-35A variant of the Lightning II, the same variant used by the U.S. Air Force. One of the selling points of buying into the F-35 Joint Strike Fighter program is cross-force interoperability. Belgium potentially operating the same variant as the USAF, Dutch and Italians may have been one factor that helped propel the potential deal for Belgium.

Still, the F-35A is still not the replacement for the Belgian Air Force F-16s: the 5th generation aircraft will face competition from the Dassault Rafale and Eurofighter Typhoon in the response to a Request for Governmental Proposal (RfGP) issued by Bruxelles last year.

The decision from Belgium is expected by mid-2018.

Belgium received U.S. authorization for the purchase of the “A” version of the F-35 shown here at Nellis AFB as operated by the USAF. (Photo: Tom Demerly/TheAviationist)



Japan’s Air Self-Defense Force also announced this week it will begin its first-ever deployment of a Japanese ASDF F-35A Lightning II at Misawa Air Base in Aomori Prefecture, northeastern Japan later this month. The single aircraft to be stationed and operated from Misawa is the first of 42 Lockheed F-35A Lighting IIs to be delivered to Japan as their primary multi-role combat aircraft. The JASDF will deploy an additional 9 aircraft operationally to Misawa by the end of 2018 bringing the total Japanese operational F-35A force to 10 aircraft by year’s end.

A key weapon system on the JASDF F-35As will be the advanced, long-range Norwegian-built Kongsberg Defense and Aerospace Gruppen Joint Strike Missile (JSM). The JSM is a variant of the Kongsberg Naval Strike Missile and is carried in the interior weapons bay of the F-35A, maintaining its low observable characteristics. The Kongsberg JSM can strike targets up to 500 kilometers away from its launch point, enabling Japan to strike many potential adversaries without leaving its own airspace, a key concern since Japan’s air force is labeled as a “self-defense force” and constrained from operations outside Japan’s legally defined defense air space in most instances.

Japan’s first F-35 will become operational this month according to Japanese media. (Photo: NHK Japan)

Finally, a story that appeared in India’s Economic Times said that, “American aerospace and defense major Lockheed Martin has proposed to manufacture custom-built F-35 fighter jets in India, which its officials say will give Indian industry a unique opportunity to become part of the world’s largest fighter aircraft ecosystem.”

The story, that appeared in Indian media on Jan. 20, 2018, did not specify what “custom built” F-35s meant, but may hint at a down-spec version of the F-35 airframe with different avionics and sensors than some other export manufactured versions of the F-35 to maintain security interests.  The same article discussed the use of the AN/APG-83 radar system, different from the AN/APG-81 on the U.S. and other partner nation F-35s.

There is no additional verification of any Indian F-35 manufacturing program in other media outlets. Oddly, another Indian media outlet, the Free Press Journal of India, published a similar story on the same day claiming the U.S. planned to build F-16s (not F-35s) in India. The Free Press Journal of India story read, “American aerospace and defense major Lockheed Martin has proposed to manufacture custom-built F-16 fighter jets (ed’s note: not F-35s as quoted in the India Economic Times article) in India, which its officials say will give Indian industry a unique opportunity to become part of the world’s largest fighter aircraft ecosystem.”

Confusing press coming out of India aside, Lockheed Martin and all of the F-35 subcontractors have to be pleased to start out the new year with a host of encouraging stories about the F-35 program.

Update Jan. 22, 19.30 GMT:

We were notified that the original version of a Press Trust of India article posted late last week, has since been corrected to remove the erroneous “F-35” reference in the first sentence of the article—see corrected article here: https://www.ndtv.com/india-news/lockheed-martin-proposes-custom-built-fighter-jets-to-be-made-in-india-1802538. The first sentence of PTI’s article now reads:

“American aerospace and defence firm Lockheed Martin has proposed to manufacture custom-built F-16 fighter jets in India, which its officials say will give the Indian industry a unique opportunity to become part of the world’s largest fighter aircraft ecosystem.”



Japanese F-4EJ Kai Phantom II Heavily Damaged in Runway Accident, Crew Escapes Fire

Hyakuri Phantom Burns on Ground, Reports Suggest Aircraft Written Off.

A McDonnell-Douglas F-4EJ “Kai” Phantom II attached to either the 301st or 302nd Tactical Fighter Squadron of the 7th Air Wing of the Japanese Air Self-Defense Force has burned on the ground at Hyakuri Air Base in the Ibaraki Prefecture of Japan. Both crew members escaped from the burning aircraft by climbing out as the fire spread.

The aircraft was taxing at the time of the accident. Press reports suggest the aircraft will be written off as a total loss. The accident happened at 11:45 AM local time in Japan on Oct. 17, 2017.

According to Japanese media and official Japanese Air Self-Defense Force reports the aircraft was participating in a training exercise in the northeastern part of Kanto, on Japan’s main island of Honshu.

The aircraft has been reported as written-off. (Photo: World Military News)

Civilian flight operations at the attached Ibaraki Airport, which shares a runway with the Hyakuri Air Base where the accident occurred, were unaffected by the fire according to reports. Ibaraki and the attached Hyakuri Air Base are 53 miles north of the Japanese capital, Tokyo. The facility operates two parallel runways, both 2,700 meters in length.

The Japanese Air Self-Defense Force is one of the few remaining users of the legacy McDonnell-Douglas F-4 Phantom II. The aircraft, built under license and serviced by Mitsubishi in Japanese service, performs a multi-role mission that includes tactical reconnaissance in the RF-4EJ version and attack roles in the F-4EJ configuration.

Video and still photos of the accident showed the two-person aircrew escaping from the aircraft by climbing out of the cockpit close to flames and heavy smoke.

The Japanese Air Self-Defense Force (JASDF) once operated 138 F-4 Phantom II’s as one of the largest international users of the prolific multi-role combat aircraft. The first Japanese F-4’s joined the 301st Hikotai Squadron in August of 1972 and have been operational ever since. There are a reported 71 Mitsubishi/McDonnell-Douglas F-4 Phantom II’s of two versions remaining in JASDF service as of April, 2017 according to Flightglobal Insight.

The Japanese F-4 Phantoms are revered among aircraft spotters worldwide as being among the last of the operational F-4 Phantoms still flying and also because of their colorful paint liveries in Japanese service that include a variety of camouflage schemes as well as solid grey aircraft like aircraft 87-8408 that was destroyed in this accident.

Top Image: A crewman escapes from burning JASDF F-4EJ Phantom II yesterday at Hyakuri Air Base. (Photo: World Military News)

Salva

These Aircraft Sampled Air For Radioactive Particles To Determine If North Korea Actually Detonated A Hydrogen Bomb

No traces of radioactive materials, including xenon gas, were detected following North Korea’s latest nuclear test. Here are the aircraft that helped determining that.

On Sunday Aug. 3, North Korea conducted its sixth and most powerful nuclear test. According to Pyongyang the test involved a hydrogen bomb that can be loaded onto a long-range missile.

The test was anticipated and observed by different intelligence gathering platforms, including U.S. spyplanes launched from Japan and South Korea, whereas air-sampling equipment installed on planes, ships and land radiation detection stations was used to look for any traces of radionuclides released after the nuclear test.

South Korea’s nuclear safety agency said it has detected no traces of radioactive materials, including xenon gas, following North Korea’s latest nuclear test: South Korea’s background radiation currently remains at the usual level of 50-300 nanosieverts per hour, apparently unaffected by the North’s nuclear test, Yonhap News Agency reported.

Interestingly the air sampling activity was carried out by at least two type of aircraft.

First of all, the quite famous WC-135 Constant Phoenix “nuclear sniffer”. The WC-135C 62-3582 was tracked as it crossed the Pacific to forward deploy to Kadena, Okinawa, from where it has alsways operated in the last months.



Then, the aircraft was tracked flying over Japan’s west coast in the morning on Sept. 6.

The aircraft is one of the two WC-135 Constant Phoenix aircraft in service today (out of 10 examples operated since the 1960s). It’s a Boeing C-135 transport and support plane derivative, operated by the 45th Reconnaissance Squadron from Offutt Air Force Base, with mission crews staffed by Detachment 1 from the Air Force Technical Applications Center.

As already reported here in the past, the WC-135 flies in direct support of the U.S. Atomic Energy Detection System, a global network of nuclear detection sensors that monitor underground, underwater, space-based or atmospheric events.

The aircraft is equipped with external flow devices used to collect airborne particulate on filter paper. The particulate samples are collected using a device that works like an old jukebox: an arm grabs the paper from its slot and moves it to the exterior of the fuselage. After exposure, it is returned to the filter magazine where a new paper is selected for use.

The mission crews have the ability to analyze the fallout residue in real-time, helping to confirm the presence of nuclear fallout and possibly determine the characteristics of the warhead involved.

WC-135W Constant Phoenix, 55th W, 45th RS, 61-2667 (Credit: AircraftProfilePrints.com)

The WC-135 62-3582 is the same aircraft that completed a “tour” in Europe, earlier this year, when it conducted several missions both in the Barents Sea area and in the Mediterranean Sea until mid March amid speculations that the aircraft had been deployed to RAF Mildenhall because of an alleged spike in Iodine levels around Norway. However, the “nuke hunter” plane was on a “pre-planned rotational deployment scheduled in advance,” according to the Air Force spokeswoman Erika Yepsen.

Interestingly, not only did the U.S. WC-135 aircraft flew to take air samples to test for radioactive particles. As already done in the past, Japan launched some T-4 training jets, equipped with collection pods, to gather air samples.

A Kawasaki T-4 (Credit: Toshiro Aoki / www.jp-spotters.com)

Actually, JASDF is able to leverage a small fleet of aircraft to perform this task: for instance, in January 2016, the day after a North Korea nuclear test, Japan deployed a C-130 Hercules airlifter and four T-4 subsonic intermediate jet trainer aircraft to gather air samples and detect radioactive particles.

To collect particles across the country, T-4 equipped with pods were launched from different bases across Japan: Misawa, Hyakuri and Tsuiki airbases located in the districts of Aomori (north), Ibaraki (central), and Fukuoka (south) respectively.

Top image credit: Ken H / @chippyho and Wikimedia Commons
