New Photos Of U.S. A-10 Thunderbolt II Refueling During Anti-ISIS Mission Show Interesting Weapons Loadout

Warthogs have started carrying 2,000 lb bombs. You won’t find many photographs of A-10s with GBU-31s.

The photographs in this post were taken from a 340th Expeditionary Air Refueling Squadron KC-135 Stratotanker during an aerial refueling mission in support of Operation Inherent Resolve on Apr. 19, 2017.

Among that mission’s receivers, there was also a U.S. Air Force A-10 Thunderbolt II aircraft.

Interestingly, the images of the “Hog” expose some changes in the weapons loadout of the A-10s involved in the fight against Daesh militants. Indeed, the aircraft depicted in the photos carries one GBU-12 Paveway LGBs (Laser Guided Bombs – on station 1 – the outmost one on the left wing), one AGM-65 Maverick missile (on station 3), one LAU-131 rocket launcher (station 2), three GBU-38 JDAMs (Joint Direct Attack Munitions – station 4, 5 and 9), one GBU-31(V)1/B with MK-84 warhead (station 7) and an AN/AAQ-28 Litening AT targeting pod (station 10).

Station 8 has a GBU-54 laser JDAM whereas the LAU-131 on Station 2 is a LAU-131A/A model used for the new (and very awesome) AGR-20 laser guided rockets.

Among the mix of missiles, guided bombs and rockets, that complement the A-10’s GAU-8 Avenger 30-mm hydraulically driven seven-barrel Gatling-type, the most interesting addition is the GBU-31, a pretty heavy (2,000-lb) general purpose bomb with JDAM (Joint Direct Attack Munition) GPS guidance system intended for mobile and fixed hard (and soft) as well as maritime surface targets.

This A-10’s worn out nose proves the Thunderbolt’s been hit several times by the flying boom during AAR operations (U.S. Air Force photo by Senior Airman Trevor T. McBride)

Although the GBU-31 is a type of weapon certified for use with the A-10 you won’t find many photographs showing other “Warthogs” carrying a 2,000-lb GBU-31: a sign that the coalition may also rely on Close Air Support platforms to hit targets which require a significant destructive power and blast radius.

A U.S. Air Force A-10 Thunderbolt II departs after receiving fuel from a 340th Expeditionary Air Refueling Squadron KC-135 Stratotanker during a flight in support of Operation Inherent Resolve April 19, 2017. The 340th EARS, part of U.S. Air Forces Central Command, is responsible for delivering fuel for U.S. and coalition forces, enabling a persistent 24/7 presence in the area of responsibility. (U.S. Air Force photo by Senior Airman Trevor T. McBride)

Salva

Salva

About David Cenciotti 4452 Articles
David Cenciotti is a freelance journalist based in Rome, Italy. He is the Founder and Editor of “The Aviationist”, one of the world’s most famous and read military aviation blogs. Since 1996, he has written for major worldwide magazines, including Air Forces Monthly, Combat Aircraft, and many others, covering aviation, defense, war, industry, intelligence, crime and cyberwar. He has reported from the U.S., Europe, Australia and Syria, and flown several combat planes with different air forces. He is a former 2nd Lt. of the Italian Air Force, a private pilot and a graduate in Computer Engineering. He has written four books.
