What These Pictures Of Two Russian Yak-130 Jets That Crash Landed Almost Simultaneously in Russia Say About The Causes Of The Mishaps

Two Yak-130 Jets Have Crashed Simultaneously in Armavir and Borisoglebsk Last Month. And Here’s An Investigation On The Root Causes.

According to several reports, two Russian Air Force Yak-130 Trainer/Light Attack (LA) Aircraft (Tail number 43white/RF-44496 from Borisoglebsk airbase and 55red/RF-44583 from Armavir) crashed almost simultaneously in two different places on Wednesday June 21, 2017. Information about incident has not released by the RuAF (Russian Air Force).

The Yakovlev Yak-130 is a subsonic two-seat advanced trainer originally developed by Yakovlev and Aermacchi (now Leonardo).

Along with the advanced jet trainer role, the “Mitten” (Yak-130 NATO’s nickname), able to replicate the characteristics of Russian Gen. 4 and 4++  combat aircraft, is capable of fulfill Light Attack (LA) and Reconnaissance tasks and it can carry a payload of 3,000 kilograms, including guided and unguided weapons, external fuel tanks and electronic pods.

The LA version, dubbed YAK-131 and equipped with mechanical radar (Phazotron) or Passive Electronically Scanned Array (PESA), is planned to replace the Su-25 Frogfoot.The Russian Air Force has also developed a reconnaissance variant of the Mitten, dubbed  Yak-133.

The Yak-130 bear a significant resemblance with Italian M-346 “Master”, produced by Leonardo Company and already operated by the ItAF (Italian Air force), IAF (Israeli Air Force), RSAF (republic Singapore Air Force) and Polish Air Force. This Author has been one of the first pilots and IP (Instructor Pilot) on the Italian T-346 (ItAF designation of the baseline M-346).

At the moment, the RuAF has not given any official information about the dual accident and the possible causes are still under investigation. However, local sources reported the first crash occurred during a normal flying training and has involved the Yak-130 (55 red/RF-44583) that belong to the Armavir Flying School.

Soon after the first crash, a second Yak-130 (43 white/RF-44496) belonging to the Borisoglebsk Air Force Base was forced to land on the runway.

INVESTIGATION ON GEAR UP LANDING. (55 red/RF-44583 Armavir)

In my career as a combat pilot, I’ve had the opportunity to undertake many different training courses. One of those was the Flight Safety Office (FSO) which include the investigation section with a simulated crash to “solve.”

By means of the methodology and approach used to investigate real incidents I’ll  drive you in a very simple and basic investigation. We will analyze all the available details and see whether it is possible to determine the causes of these crashes.

55 red/RF-44583 from Armavir after the crash landing (via Ilya.A—Petya.A’s bro)

Close up view of the left air intake of the Yak-130 (via Ilya.A—Petya.A’s bro)

First of all, what we can do is a “picture analysis” and looking at the picture of 55 red/RF-44583 you can notice some of important details useful to understand the landing or crash dynamics:

  1. The aircraft landed on the belly without any other damage or structural breaks: this means the aircraft touched the ground with a correct and normal attitude used during a normal landing. Therefore, we can assume the pilot “planned” to land on the grass;
  2. The aircraft had the LEF (Leading Edge Flap) in down position: this means the pilot lowered the LEF with the intent to land like he was on the runway;
  3. The canopy seems to be open in a normal way (no damage or glass rupture): in other words the two pilots abandoned the aircraft “normally” soon after the jet stopped. This detail suggests the pilot purposely landed there and did a soft touch down with no other consequence;
  4. Looking at the air intake, you can see the internal section extremely clean without any FOD: this means the engine was not running and it didn’t suck anything. One possible reason is a flame out or the pilot decided to shut down the engine seconds before the touchdown to avoid any fire.

After a FIR (First Impression Report), the second step is to merge all the above consideration in order to elaborate a possible scenario. Based on the above points, the two pilots most probably attempted an emergency landing with one or both engines not operating.

Now let’s move to the possible causes that forced the Yak-130 to land out of the runway and let’s try to understand WHY the pilot did take the decision to land on grass field.

First consideration is that the emergency was TIME CRITICAL, otherwise they could have enough time to fly and steer toward a suitable airfield. Based on my experience the most important hint comes from the picture of the air intake: this picture seems to suggest engines or thrust problems that forced the pilot to perform a forced landing out of the runway. Let’s explore possible reasons:

  1. The aircraft was completely out of fuel. This situation seems quite unlikely, almost impossible, unless aircraft showed false fuel indications (a case of multiple emergencies, that is to say fuel transfer failure combined with false fuel indication) because pilots use to plan the fuel required for all training tasks: the fuel to recovery to the base with enough fuel in case they need or to practice some visual pattern; and the fuel to divert to the alternate in case of problem with the home base;
  2. The aircraft had a fuel transfer failure and the crew suddenly found to have less fuel available to return home or to the nearest suitable airfield;
  3. The aircraft had a double engine flame out (this option can be also caused by the point 1 and 2) and the pilots were forced to find a suitable “strip” to land.

Of course I don’t know the RuAF SOP (Standard Operations Procedures) and the YAK-130 emergency check list procedures for the above emergencies.

In case of double engine flame out, due to fuel or engines malfunction, most of the military aircraft procedures require the pilots to eject unless they can safely recover or land the aircraft. Landing on the grass without gear is not a safe recovery but in this case (I want to remember that we don’t know too many details about the reason of crash and we are conducting an investigation based on a picture) pilots took a very brave decision and the option to land without landing gear was in the end a smart decision to soften as much as possible the touchdown on an “unprepared field”. In this case pilots took a huge risk but they were extremely lucky to land without further problems (such as fire, structural damage, unintentional ejection seat activation and so on.)

Although we can’t rule out multiple failures, such as engine flame out and landing gear system failure, my instinct and experience suggest that the gear up landing was done on purpose.

INVESTIGATION ON NOSE GEAR UP LANDING (43 white/RF-44496 Borisoglebsk)

The 43white/RF-44496 from Borisoglebsk (via Ilya.A—Petya.A’s bro)

Looking at the picture, the aircraft seems to have landed normally with few damages. This assessment helps limiting the range of possible failures that may have caused the gear up landing, because we can assume the aircraft was operating efficiently.

Since the plane seems to have landed normally (making engine failure less likely unless this has happened in the vicinity of the airfield) we can focus on a possible landing gear system malfunction. Therefore, let’s have a look at some details:

  1. The aircraft has the LEF down and we already know why and what this may mean;
  2. Only the main landing gear is down: this may have been caused by nose landing gear malfunction, structural damage due to bird strike, nose landing gear not completely locked or hydraulics malfunction;
  3. The main gear doors seem to be in open position. Most of the military jets, when reporting landing gear malfunction or hydraulics system failure, have the option to use the emergency gear lowering system. When the pilot activates the Emergency lowering system this overrides the normal gear system using enough pressure to lower the gear but not enough to close the gear doors. On the other side I cannot be 100% sure about this because of the picture resolution; still, during incident investigations it is important to take how systems work into proper consideration.

At this point, merging all the above points we can assume that the aircraft had some problem with landing gear system or hydraulics system and the pilot decided to land without nose gear.

During a nose gear-up landing it is paramount for the pilot to comply with the following action list:

  • Be very precise on approach with speed and attitude;
  • Perform aerodynamic braking during landing roll;
  • Before the HT (Horizontal Tail) loses lift, the pilot needs to gradually reduce the back pressure on the stick to allow a soft touchdown between the ground and the airframe;
  • Re-apply again the back pressure on the stick as soon as the nose touches the ground to reduce the weight on the nose trying to minimize the damage.
  • Avoid to use the brakes;
  • Shut down the engine in order to avoid engine mechanical failure and reduce thrust and, consequently, the landing distance.

According to my experience most of the aircraft are allowed to land with a symmetric configuration like: NO GEAR, ONLY MAIN GEAR, ONLY NOSE GEAR.

Summing up, based on a few pictures we can conclude that:

  • the aircraft 55 red/RF-44583 from Armavir had some problem with fuel quantity/transfer or with both engine and the pilot was forced to land on the grass
  • the aircraft 43 white/RF-44496 from Borisoglebsk had some problems with landing gear system or hydraulics system.



Salva

Salva

Salva

The Italian Air Force Predator A+ Drones Appear With Brand New Markings At New Squadron Activation Ceremony

The Italian Air Force Predator A+ of the 32° Stormo (Wing) appear with new markings.

On Jul. 10, the Italian Air Force announced the reactivation of the 61° Gruppo (Squadron), disbanded in 1943, at Sigonella airbase, in Sicily, that will operate the MQ-1C Predator A+ UAS (Unmanned Aerial Systems) as a detached unit of the 32° Stormo, headquartered at Amendola, southeastern Italy.

The drones, piloted by aircrews coming from the 28° Gruppo and supported by ground crews of the 41° Stormo, based at Sigonella, will reinforce the Italian surveillance capabilities in southern Italy.

The new squadron will complement the other squadron of the 32nd Wing, the 28° Gruppo also based at Amendola, that already operates a mixed force of MQ-9 Reaper and MQ-1C Predator A+ drones that are used to undertake a wide variety of tasks: along with the standard ISR (intelligence Surveillance Reconnaissance) missions, the Italian Predators have supported MEDEVACs (Medical Evacuations), TIC (Troops In Contact) operations, IED (Improvised Explosive Devices) monitoring, Convoy Escort in Iraq and Afghanistan; they have supported Operation Unified Protector in Libya, Mare Nostrum operation in the Mediterranean Sea near Lampedusa (where they have monitored the migratory flows and consequent tragic ship wreckage off the island) and, from Djibouti, have monitored the seas off the coast of Somalia in anti-piracy missions. They are also currently deployed in Kuwait to support the US-led anti-ISIS operation in Syria and Iraq. Leveraging their persistence on the target area, the drones have also supported Police forces during major events.

Noteworthy, the photos of the 61° Gruppo reactivation ceremony posted by the Italian Air Force on social media exposed an interesting detail.

Indeed, for the very first time, the Predators belonging to the 32° Stormo appear to sport the standard Wing’s livery that includes the aircraft code 32-xx on the fuselage and the Wing’s emblem, the Hawk, on the the tails.

One of the Italian MQ-1C Predator A+ drones sporting the individual code 32-33.

With the addition of the new markings, the Predators of the 61° and 28 ° Gruppo will now feature the same kind of markings worn by the F-35A Lightning II aircraft of the 13° Gruppo of the 32° Stormo, Italy’s first JSF squadron that has recently celebrated its 100th anniversary (with special tail markings.)

Close up view of the Hawk applied to the tails of the Predator.

Image credit: ItAF

Salva

Salva

Up Close And Personal With The Italian Typhoon Jets Deployed To Bulgaria Under NATO’s Enhanced Air Policing

Four Italian Typhoons have deployed to Bulgaria to bolster NATO’s Air Policing mission in the Black Sea region.

Four Italian Air Force F-2000A Typhoon jets have deployed to Graf Ignatievo Air Base, Bulgaria, to undertake the NATO’s enhanced Air Policing mission from July until October 2017.

The Italian Typhoons belong to the 4° Stormo (Wing) of Grosseto, 36° Stormo from Gioia del Colle and the 37° Stormo from Trapani even though, as always happens when involved in real operations, the Italian aircrews will operate as part of a Task Force where, regardless of the unit, badges and traditions (all the squadrons involved in the deployment have recently celebrated their centenary…) all personnel, aircraft and equipment are completely integrated and interchangeable, thanks to fully standardized procedures and training.

The Italian rotation to Bulgaria will overlap until September with the RAF detachment of four Typhoons deployed to Mihail Kogalniceanu air base in Romania as part of the same Southern Air Policing mission.

Following a familiarization phase, the Italian team will undergo certification by NATO’s Combined Air Operations Centre (CAOC) Torrejon, Spain before providing Air Policing tasks alongside the local Bulgarian Air Force MiG-29 Fulcrum jets.

The Italian F-2000As on the ramp at Graf Ignatievo Air Base.

A Bulgarian Air Force Fulcrum taxies next to the Italian Typhoons.

Since Bulgaria “is perfectly able to conduct NATO Air Policing with its assets; this enhanced Air Policing capability offered by the Italian jets provides the CAOC with more flexibility to conduct the mission.”

This is the first time the Italian Typhoons take part in the NATO’s Enhanced Air Policing mission in the Black Sea area: so far the ItAF “Tiffies” have supported the Icelandic (in 2013 and earlier this year) and Baltic (in 2015) while supporting the Interim Air Policing task over Slovenia (task shared with the Hungarian Air Force) and over Albania (task shared with the Hellenic Air Force).

Typhoon’s rear view.

One of the ItAF Typhoons parked at Graf Ignatievo Air Base, Bulgaria, after its arrival on Jul. 7.

Breaking for landing

“While Air Policing is a collective peacetime task to ensure integrity and security of NATO airspace, the enhanced Air Policing was agreed and implemented by NATO Allies at the Wales Summit in 2014 under the Assurance Measures. These measures are aimed at assuring Allies along the NATO’s eastern flank of Alliance commitment and resolve as well as deterrence and defence,” said NATO in an official release about the deployment.

The images in this post were taken by Nikolay Dimov at Graf Ignatievo as the Italians landed to support the Air Policing task in Bulgaria on Jul. 7, 2017.

Two of the four IRIS-T air-to-air missiles carried by the Italian Typhoons in Bulgaria.

Typhoon head on: take a look at the loadout.

Image credit: Nikolay Dimov



Salva

Check Out The Four Italian Eurofighter Typhoons In New, Stunning Special Color Schemes

Four F-2000A Typhoon jets, each wearing a unique special livery, were unveiled on Jun. 24 at Grosseto airbase.

As already reported, on Saturday Jun. 24, Grosseto airbase hosted the event that celebrated the 100th anniversary of five Italian Air Force squadrons: the IX Gruppo (9th Squadron, using the Roman numerals), belonging to the 4° Stormo (Wing), based at Grosseto; the X and XII Gruppo (10th and 12th Squadron), both belonging to the 36° Stormo, Gioia del Colle; the XIII Gruppo (13th Squadron), with the 32° Stormo from Amendola; and the XVIII Gruppo (18th Squadron), belonging to the 37° Stormo, based at Trapani.

Along with the world’s first ever F-35A with special tail markings presented by the XIII Gruppo, the IX, X, XII and XVIII, that fly the Eurofighter Typhoon, unveiled their special colored F-2000A jets.

The IX Gruppo special, MM7340/4-9, was designed by Silvano Mainini and Andrea Scomparin (who are also behind many other famous paint jobs including the special liveries of the last Grosseto F-104 Starfighters back in 2003). It sports the squadron’s white rearing horse and “9” squadron number on the left hand side of the tail and the horse and IX numeral on the right one.

The IX Gruppo special landing at Grosseto on Jun. 25, 2017. (image credit: The Aviationist’s Alessandro Fucito)

The left hand side of the MM7340/4-9 (image credit: The Aviaitonist’s Alessandro Borsetti)

The X Gruppo special, MM7341/36-10 was designed by Lt. Giovanni D’Antonio and features Francesco Baracca’s black rearing horse along with a red “Picca” (pike – from the unit’s radio callsign).

The X Gruppo special: MM7341/36-10 (credit: Alessandro Fucito)

The “Picca Special” prepares to land on Sunday Jun. 25 after taking part with all the other specials, including the F-35, in the Marina di Grosseto airshow (credit: Alessandro Fucito)

MM7318/36-12, the XII Gruppo special jet was designed by our friend Ugo Crisponi and features the rearing horse on a sand background, along with the silhouettes of all the aircraft flown by the squadron since 1917.

The special 36-12 about to land in Grosseto (credit: Alessandro Fucito)

Another view of the MM7318/36-12. This photo was taken as the aircraft arrived in Grosseto on Friday Jun. 23, 2017 (image credit: The Aviationist’s Giovanni Maduli).

The XVIII Gruppo special colored Typhoon MM7293/37-18, once again made by Mainini and Scomparin, has a different scheme on the right and left side of the tail: the right one shows the “Vespa Arrabbiata” (Italian for Angry Wasp) of the 3° Stormo to which the squadron belonged during WWII; the left side shows the XVIII numeral superimposed to the typical green and black checkerboard.

The MM7293/37-18 on the ground at Grosseto during the centenary celebrations (credit: Alessandro Borsetti)

This photo of the 37-18 shows the livery on the right hand side of the aircraft (credit: Alessandro Fucito)

As the photos in the post show, all the aircraft had the airbrake and canards painted as well.

In a world of military aviation dominated by overall grey paint schemes, some colour is much appreciated by enthusiasts, photographers and spotters!



Salva

Salva

Here Are The World’s First F-35A Lightning II Stealth Aircraft With Special Tail Markings

Two Italian Joint Strike Fighters were given special tail markings to celebrate the 100th anniversary of the 13° Gruppo.

On Saturday Jun. 24, 2017, the Italian Air Force celebrated the 100th anniversary of five of its most famous combat squadrons: the IX Gruppo (9th Squadron, using the Roman numerals), belonging to the 4° Stormo (Wing), based at Grosseto; the X and XII Gruppo (10th and 12th Squadron), both belonging to the 36° Stormo, Gioia del Colle; the XIII Gruppo (13th Squadron), with the 32° Stormo from Amendola; and the XVIII Gruppo (18th Squadron), belonging to the 37° Stormo, based at Trapani.

During a event, held at Grosseto and gathering personnel from all the centenary units, each of the five squadrons unveiled aircraft in special color scheme. Therefore, whilst the IX, X, XII and XVIII, flying the Eurofighter Typhoon, unveiled their special colored F-2000A jets (that we will cover in an upcoming post), the XIII, Italy’s first JSF unit, displayed an F-35A aircraft with special tail markings (on the left hand tail only).

Although not the standard tail markings, the still rather simple celebratory markings include the Italian flag along with a large 13° Gruppo’s emblem, Don Quixote, with the addition of a “100” number and the dates 1917-2017.

The detail of the special markings applied to the ItAF F-35As.

Here are the “standard” markings worn by the Italian F-35A: the Stormo badge along with the individual 32-xx code (credit: ItAF)

Actually, the tail markings have been applied to two aircraft, the MM7336/32-05 and the MM7357/32-07, that flew to Grosseto alongside the MM7337/32-13 on Friday Jun. 23, at the end of the Italian Air Force’s first three-ship F-35 mission.

MM7336/32-05 with the special markings on the left vertical tail.

As already reported, on Dec. 12, 2016, Italy received its first two F-35A Lightning II, becoming the very first country to take delivery of the 5th generation stealth jet outside of the U.S. in what was just one of the several “firsts” scored by the Italian Air Force with the JSF: on Dec. 3, 2015, the Italian Air Force welcomed the first F-35A assembled and delivered outside the U.S. at the Final Assembly and Check Out (FACO) facility at Cameri, in northwestern Italy.

Then, on Feb. 5, 2016 in the hands of an ItAF test pilot, an Italian F-35 successfully completed the type’s very first transatlantic crossing landing at Naval Air Station Patuxent River, Maryland. More recently, the first F-35B assembled internationally has rolled out of Cameri FACO.

Considered that the previous JSF in special color tails or high visibility markings were either B or C models (and mostly prototypes), those unveiled by the 13° Gruppo on Jun. 24 are, to our knowledge (and if we missed any previous “special” Lightning CTOL variant let us know) the very first operative F-35As in special tail markings. Another Italian first with the 5th generation aircraft.

One of the Italian F-35s taking off from Grosseto. This is the flagship aircraft of the 13° Gruppo belonging to the 32° Stormo (hence the code 32-13). Image credit: The Aviationist’s Giovanni Maduli.
