F-35 Achieves Milestones Amid Setbacks And Criticism

Joint Strike Fighter is Still a Lightning Rod of Criticism, But Progress Continues.

Photos and Video by Lance Riegle unless otherwise stated. Story by Tom Demerly and David Cenciotti.

The F-35 Joint Strike Fighter program reached several developmental milestones in August 2018 despite ongoing criticism of the program’s costs and reported technical concerns. As the effort to integrate the weapons system into participating air forces accelerates, the obstacles and challenges faced by the F-35 begin to appear more economic and political, and less practical and technical.

The airplane is beginning to work mostly as advertised, with the U.S. Air Force leading the integration into the force structure within the United States. The Navy and Marines continue to resolve technical challenges as their F-35 integration progresses, even though a recent POGO investigation has exposed that “program officials are recategorizing – rather than fixing – some of the aircraft’s design flaws, likely in an attempt to keep the from blowing through another deadline and budget cap.”

The U.S. Air Force is currently investigating the cause of last week’s nose gear collapse at Eglin Air Foce Base, while the Navy has begun to moderate the causes of the nose wheel oscillating vertically during catapult launches at some aircraft weights. The Navy is also working to resolve a helmet visibility problem that compromises the pilot’s view of aircraft carrier’s landing light systems at night. Until the solution is achieved for the F-35C, night landings at sea are restricted to experienced pilots. The Marines have asked for special lightning rods to prevent their recently deployed aircraft from being struck by lightning on the ground, a problem that could damage aircraft electronics. Some foreign F-35 operators will have the ability to block the F-35’s systems from sending data back to the U.S. through the Sovereign Data Management (SDM) system. This will create a sort-of operational security firewall for the much criticised Autonomic Logistics Information System (ALIS).

Perhaps the most adversarial environment for the F-35 is not denied airspace over Syria or Iran. The real high-threat environment for F-35 seems to be the no-rules, asymmetrical battlespace of social media.

In the late 1950s and ‘60s when the North American F-100 Super Sabre and Republic F-105 Thunderchief multi-role combat aircraft were in development major accidents were frequent. During the early testing and integration of the first production supersonic fighter, the F-100 Super Sabre, one aircraft was lost or damaged nearly every three days. The F-100’s own chief test pilot, North American’s George Welch, died in a 1954 crash.

Nearly half of the Republic F-105s were lost by the end of the Vietnam conflict, most to enemy action, but some in accidents before the aircraft ever deployed. Some of the F-105 accidents were high profile even before social media. One F-105 broke in two during use by the Air Force Thunderbirds. Another F-105 crashed in a Las Vegas neighborhood on May 13, 1964, killing three children and a woman on the ground along with the pilot. Eight houses burned in the crash. The F-105 was grounded pending safety investigations that revealed several dangerous problems that were subsequently repaired.

Acknowledging that the F-100 and F-105, along with the F-104 Starfighter, were among the first to fly at supersonic speeds, their technological progression from the previous generation aircraft, the P-80 Shooting Star and F-86 Sabre, could be regarded as similar to the differences between modern F-15s and F-16s and the F-35 Joint Strike Fighter.

While there are ongoing problems with the F-35, these could be characterized as lesser than the potential context of the entire program and the arc of advancement in its key technologies. A primary challenge facing the overall F-35 program is not the technology of the aircraft itself, but the inability of the public to grasp what the F-35 actually will do. It is like trying to convince the owner of a $40 rotary telephone that a $700 iPhone is worth the upgrade, especially when they learn the battery can die and render the phone inoperable.

Integrating the F-35 into a modern and evolving battlespace has been as much a public affairs and perception challenge in the social media age as the technical challenges the program faces.

The debate between F-35 supporters and critics escalated in July 2015, when War Is Boring obtained a brief that claimed the F-35 Joint Strike Fighter was outclassed by a two-seat F-16D Block 40 (one of the aircraft the U.S. Air Force intends to replace with the Lightning II) in mock aerial combat.

TheAviationist.com researched and debunked some theories about the alleged capabilities of each F-35 variant to match or considerably exceed the maneuvering performance of some of the most famous fourth-generation fighters. Our analysis also also made a strong case that there is probably no way a JSF will ever match a Eurofighter Typhoon in aerial combat. Our editors also highlighted that the simulated dogfight mentioned in the unclassified report obtained by War Is Boring involved one of the very first F-35 test aircraft that lacked more recent upgrades in currently fielded F-35s.

In March 2016, we published an article written by Major Morten “Dolby” Hanche, an experienced Royal Norwegian Air Force tactical pilot with more than 2,200 hours in the F-16. Major Dolby is also a U.S. Navy Test Pilot School graduate and the first Norwegian pilot to fly the F-35. In that post “Dolby” provided a first-hand account of what dogfighting in the controversial F-35 looked like to a pilot who had a significant experience in the F-16 along with formal experience as a flight test and analysis pilot.

A 33rd Fighter Wing F-35A Lightning II is towed to its airshow display location. (Photo: Lance Riegle)

At the first Red Flag combat simulation exercise the F-35 participated in during early 2017 reports claimed the aircraft achieved a “15 to 1” kill ratio. But one noted journalist, Tyler Rogoway of “The Warzone”, wrote:

“The 15:1 kill ratio in particular is nebulous, because it seems this may be skewed in terms of what data it actually includes. Kill ratios attributed to a platform naturally make us think of direct engagements with enemy aircraft, but Red Flag is a highly integrated air battle, one that always uses the latest data-link fusing gateways and other force-multipliers. It remains unclear whether the stated kill ratio is strictly attributable to the F-35, or if it includes the actions of other coalition aircraft, particularly F-22s, while the F-35 is merely present.”

Rogoway’s insight into the “15 to 1 kill ratio” highlights the traditional air combat paradigm that, if a missile didn’t fly off an aircraft’s wing, that aircraft didn’t score the kill. But the F-35 doesn’t work that way. A key F-35 technology is sensor fusion. Sensor fusion is pulling in targeting data from sensors on other platforms such as surveillance aircraft or shipborne surface radars. The F-35 can then “hand-off” targets to other weapons platforms, effectively scoring a kill that would not have otherwise happened, but without firing a shot itself.

This is what TheAviationist.com’s Chief Editor David Cenciotti wrote back then:

Well, after eight days “at war”, in spite of being “just” IOC (Initial Operational Capable – the FOC is expected next year with Block 3F) the F-35A Lightning II is proving to be an “invaluable asset” during Red Flag 17-01, the Air Force’s premier air combat exercise held at Nellis Air Force Base, Nevada: its ability to gather, fuse, and distribute more information than any other fighter in history provide the pilot with vital situational awareness that can be exploited to escape (and engage?) highly sophisticated and lethal enemy ground threats and interceptors.

Actually, the extent of the F-22 Raptors contribution to the above mentioned kill ratio is not clear: the F-35s are flying alongside Raptors and, as one might expect, the F-22s take care of the aggressors whilst the F-35s slip undetected through the surface-to-air defenses until it reaches the position to drop munitions at the target.

Considered that the F-22s are providing air cover to the Lightning IIs, is the 15:1 score a team result or the actual kill ratio of the F-35A?

There’s been much debate about the kill ratio of the F-35 made public after air-to-air engagements against other aircraft (namely the F-15E during a similated deployment last year).

In other (F-35) news…

Diplomatic wrangling surrounding the program has created the most sensational turbulence, and one significant stall in the case of the delayed Turkish program deliveries. The first Turkish pilot to fly an F-35A Lightning II, Major Halit Oktay, flew the aircraft at Luke AFB near Phoenix, Arizona on August 28, 2018. The Turkish news outlet “Daily Sabah” reported the flight on Wednesday.

A report also surfaced this week that the U.S. was trying to convince Turkey to “Give Up S-400s and Get F-35s” according to a headline on the HurriyetDailyNews.com Turkish news outlet. The U.S. has voiced security concerns about Turkey employing both Russian designed S-400 surface-to-air missile systems and the F-35A Joint Strike Fighter. The concerns have resulted in a delay in providing F-35As to Turkey even as the U.S. continues to train Turkish F-35 pilots at Luke AFB. The S-400 missile system is claimed to have “anti-stealth” capabilities that could pose a threat to the F-35. U.S. lawmakers are concerned that one country using both weapons systems may compromise the security of some aspects of the F-35 program.

The U.S. Navy also achieved an F-35 milestone this week when the first F-35C integrated flight operations were conducted from the aircraft carrier USS Abraham Lincoln (CVN-72). It was the first time U.S. Navy F-35C Lightning IIs operated as an integrated part of a carrier-launched strike package. F-35Cs from Strike Fighter Squadron (VFA) 125, the “Rough Raiders”, from Naval Air Station Lemoore conducted their Operational Test-1 (OT-1) with Carrier Air Wing (CVW) 7 and Carrier Strike Group 12 aboard the Nimitz-class aircraft carrier USS Abraham Lincoln. The unique, wide-winged Navy F-35Cs flew in coordination with F/A-18s and other aircraft while integrating with a navy air wing conducting cyclic missions.

180820-N-FK070-2050
ATLANTIC OCEAN (Aug. 20, 2018) An F-35C Lightning II from the Rough Raiders of Strike Fighter Squadron (VFA) 125 prepares to launch from the flight deck of the Nimitz-class aircraft carrier USS Abraham Lincoln (CVN 72). (U.S. Navy photo by Mass Communication Specialist 1st Class Brian M. Wilbur/Released)

The Italian Air Force, quite “shy” about its most advanced aircraft, is sending one of their F-35As to take part in the first European airshow at Belgian Kleine-Brogel Air Base on Sept. 8-9.

Other upcoming milestones in the F-35 program will include the first flights of the British F-35s from their new aircraft carrier, the HMS Queen Elizabeth, scheduled for early next year off the U.S. coast. The tests will initially use U.S. aircraft but likely be flown by British pilots. Meanwhile, the British have carried out the first trials out of Edwards Air Force Base, California, carrying UK-built ASRAAM missiles.

On the other side, it’s a bit of a mystery why the F-35 that have arrived to the UK haven’t flown in over a month as reported by Aviation Week. According to the MoD this was caused by maintenance checks as well as personnel leave and will have no impact on achieving the IOC (Initial Operational Capability) in December…

While the F-35 program has received valid criticism over its cost the program is showing signs of providing economic returns. Lockheed Martin stock has climbed from $122.42 per share five years ago to its Wednesday close of $321.29. The stock has lead the defense financial sector with a five year increase of 89.63% while returning a dividend yield of 2.5%. Lockheed Martin also honored a commitment to hire 1,800 new employees for the F-35 Lightning II Joint Strike Fighter program.

The recent milestones in the overall F-35 Joint Strike Fighter program are important to consider set the against the backdrop of publicized problems within the program. While many of the concerns facing the F-35 development are valid and significant, according to all the analysts and pilots we have talked to, they could be characterized as “the new normal” for a program as vast as the Joint Strike Fighter. For this reason, as long as the current trend of developmental advances in the program begin to outpace the ongoing concerns over costs and technical evolution, the F-35 Joint Strike Fighter program will likely emerge as a net gain in a technical space where there is no second place.

Check Out This Nostalgic 1981 U.S. Navy Commercial Featuring the F-14 Tomcat

It’s short but worth watching.

The video below is a U.S. Navy commercial dating back to the 1981. In the early eighties the F-14 Tomcat was the Navy’s premier fighter: inducted into active service beginning in 1974, the legendary aircraft had already replaced the F-4 Phantom II in most Carrier Air Wings aboard US aircraft carriers. Actually, in 1981, the F-14 had its first air-to-air kills during what became known as the First Gulf of Sidra incident. In that aerial engagement, on Aug. 19, 1981, two F-14s from the VF-41 Black Aces downed two Libyan Su-22 Fitters.

Anyway, few years before it starred in Top Gun movie, the F-14 served as “U.S. Navy’s best recruiting tool” in a short clip that will bring you back to the “1980s”!

By the way, the aircraft you can see in the commercial is the F-14A Tomcat modex “212” belonging to VF-2 “Bounty Hunters”, a squadron assigned to CVW-2 deployed to sea (WestPac and Indian Ocean) aboard USS Ranger (CV-61) between Sep.10, 1980 and May 5, 1981. The aircraft sports the striking high-visibility camouflage/color scheme and markings that were used on Navy’s combat aircraft in that period before they were replaced by the overall grey low-viz patterns.

The airbase appears to be NAS Miramar (now MCAS Miramar).

Noteworthy, the commercial focused on the pilot alone, forgetting the other Tomcat’s crewmember: the RIO (Radar Intercept Officer).

VX-23 Air Test & Evaluation Super Blues Transition Patch Emerges On eBay

The Blue Angels will Receive the F/A-18E/F in 2021. But testing of the Super Hornet is already underway.

As already reported, the Blue Angels will take delivery of the Super Hornets to replace their “Legacy” F/A-18C/Ds in late 2021 in time to work-up for the following airshow season.

However, the Boeing F/A-18E single seat and F/A-18F two-seat Super Hornet that will be flown by the U.S. Navy Flight Demonstration Team will be fleet aircraft modified for airshow demonstration; they will feature biodegradable colored smoke injectors, fuel flow modifications to facilitate extended inverted flight and the addition of 7-pounds of forward hydraulic force on the control stick when maintaining level flight to improve the handling of the aircraft in turbulent, close formation flying.

Interestingly, the testing of the “new” Rhinos (as the Super Hornets are dubbed within the U.S. Navy – yes, exactly as the F-4….), is currently underway and according to our sources it is expected to be complete by the end of this year. The Air Test and Evaluation Squadron Two Three (VX-23), NAVAIR’s largest flight test organization based at NAS Patuzent River, MD, has already produced a patch that you can find on eBay here. Curiously, the “2016-2017” text suggests the VX-23 activities were completed last year even though the testing is currently underway: after investigating this a little, we have found out that the squadron ordered the patches back in 2017, before the testing was postponed to this year.

For this reason the official patch with the “wrong dates” has been around for some time and is probably going to become a collectors must!

Dealing with the VX-23 “Salty Dogs”, here are some details from the Naval Air Warfare Center webpage:

“The squadron’s mission is to support the RDT&E of fixed wing tactical aircraft by providing aircraft and pilot assets, maintenance services, safety oversight and facility support for these efforts. Primary areas of support include flying qualities and performance evaluations, shipboard suitability, propulsion system testing, tactical aircraft mission system testing, ordnance compatibility and ballistic efforts, reliability and maintainability assessments, flight fidelity simulation and flight control software development. The Squadron also provides Government Flight Representatives, test monitoring, chase aircraft support, and facilities for contractor demonstration, validation and development work involving tactical aircraft and associated systems.

The VX-23 workforce — officers (Navy, Marine Corps and foreign nationals), enlisted (Navy and Marine Corps), civilians and contractors — supports the aircraft maintenance, test planning and conduct, safety oversight and support of the squadron’s F/A-18A-D Hornets, F/A-18E/F Super Hornets, EA-18G Growlers, and T-45A/C Goshawk aircraft, and the on-going contractor demonstration efforts with F-35B/C Lighting II aircraft. VX-23 is also supported by hundreds of flight test engineers and technicians provided by the Integrated Systems, Evaluation, Experimentation and Test Department and various contractors.

The squadron conducts more than 3,000 flight operations annually, totaling approximately 4,400 flight hours, much of which involves high-risk flight test. VX-23 conducts operations, both shore based and shipboard, locally at NAS Patuxent River and operates and maintains the TC-7 catapult and MK-7 arresting gear test sites.”

We will continue to follow the Super Blues Transition and provide more details as they becomes available.

Top image credit: ebay User “patchquest”

All The Highlights of the Spectacular Aerobaltic 2018 Air Show in Gdynia, Poland.

Many interesting warbirds have taken part in the Polish airshow.

Last year the Polish Aeropact company organized the first edition of a beach air show, known under the name Aerobaltic in Gdynia. The show took place at the main city beach in Gdynia, Poland, and was generally received as a major success, with daytime and evening/night flying program. This year, on the other hand, the organizers decided to expand and divide the event into two parts: the daytime program was organized at the Gdynia Kossakowo/Babie Doły airport, while the evening/night portion of the flying took place at the beach, similarly to last year.

The Babie Doły flying program evoked a lot of hope, as this year’s edition of the event was to include the military jets too. And so it did. TS-11 Iskra jet trainer, privately owned by the White-Red Wings foundation took part in the show. Another highlight – undoubtedly – came in a form of the Swedish Air Force Historic Flight team that brought some unique airframes to Gdynia. It was the first time that this Author saw the Lansen, single-seater Draken or twin-seater Viggen jets in the air, all constituting a somewhat special point of the flying program. The Swedish participation was also complemented by a flying display performed by J29 Tunnan – a very exotic Saab’s design dating back to the 1950s – the “Ikea Air Force’s” display was thus presented in all of its glory.

The Saab J29F Tunnan.

The Saab 32 Lansen of the Swedish Air Force Historic Flight team.

The Saab Draken.

The legendary Saab Viggen.

Baltic Bees jet team was another of the jet-powered points of the flying program.

One of the L-39 of the Baltic Bees team.

Another highlight of the Babie Doły portion of the show came in a form of the Orlik Team of the Polish Air Force. To commemorate the Polish Air Force’s centenary, the team has prepared a special program this year, with the display involving Canadian Harvard trainers that were, back in the day, used as the trainer platform by the Polish aviators. The coordination and level of precision achieved between the aircraft involved in the program is undoubtedly a sight to behold. The Polish Air Force’s MiG-29 display was also scheduled for Aerobaltic, unfortunately the jets have been grounded, along with the Su-22s, at least until September, or longer. The Polish Navy, meanwhile, also presented the W-3WARM SAR helicopter in a role demo display. The Jordanian Air Force, on the other hand, had the Royal Jordanian Falcons participate in the Gdynia show, and the group also showcased a high-precision display on their Extras.

W-3WARM SAR helicopter in a role demo display.

The “civil” participants included aerobatic pilots, such as Maciej Pospieszyński or Stijn De Jaeghre, or the only Polish participant of the Red Bull Air Race series: Łukasz Czepiela. Red Bull’s Czech ‘The Flying Bulls’ team also took part in the show. 57-my team flying autogyros and Sydney Charles Display Team flying the Grob motor-gliders were also performing their programs at Babie Doły. Artur Kielak, another of the show’s participants, has prepared an interesting flying program with a Polish privately owned Yak-3U – with numerous crossings and interesting formation shifts. Swiss P3 Flyers team has also been a rarity, and it was really nice to witness the vintage trainers in the air over Gdynia Babie Doły.

Swiss P3 Flyers team.

Aerobaltic air show would not have been complete, had it not been for the sunset/night portion of the show at the beach, from which the event originated in the first place. The evening/night program was to some extent identical to the daytime one (Kielak/Yak-3U flown by Mateusz Strama), however most of the highlights for the evening/night show were different. And most of them utilized pyro element making the evening show even more spectacular, offering a lot of unique photo opportunities. Johan Gustafsson and Sydney Charles Display Team were the highlights of the night show, with their pyro display being especially rich.

The night part of the show is always breathtaking.

Overall though, the night show was not as good as the one during the first edition of the event. Maybe it would also be a good idea to have some of the jet-powered aircraft perform at the beach over the water, which could possibly produce some spectacular effects such as vapor cones. In general, the event bears a significant potential, and we should only hope that the Aeropact company which is the organizer of the show would not let it go to a waste. Fingers crossed, and we highly recommend attending this show next year!

All images: Jacek Siminski

What’s this mysterious aircraft spotted at Edwards AFB? The secretive B-21 Raider, the RQ-180 drone or “just” a B-2?

The U.S. Air Force says it’s a “standard” B-2, but a pretty detailed analysis and some subtle details seem to suggest it might be something else.

The photographs you can find in this post were taken by three of our readers (Sammamishman, Zaphod58 and Fred) who have recently returned from a trip to monitor activities at Palmdale and Edwards Air Force Base, California.

These guys are not the average avgeeks. All the three either worked or are currently working around aircraft (one has worked on an Air Force Base ramp for many years and is well-respected as an aircraft guru, another works as an air medic and one is in the aerospace industry involved in advanced space and defense-related components) and they are extremely familiar with aircraft they observe and photograph with some high-end equipment. Sammamishman is the reader who sent us the video and photographs of the F-117s flying over Tonopah Test Range in 2016.

Among the things the trio photographed, there is also an unknown large flying wing type aircraft, hooked to a ground power unit, sitting on an apron located at Edwards South base between the hours of 10PM and 1AM on July 24-25, 2018.

The three spotters sent the images to the Air Force to determine if it is a classified article and subject to DoD censorship. After reviewing the images for a few days, the Air Force responded it was a B-2 Spirit.

“I however disagree with this story for several reasons that I will go into,” says “Sammamisham” in an email.

“Upon initial examination of the photos that night when we took them, it looked like a B-2 but under closer examination the proportions and fuselage configuration didn’t look right for a Spirit”.

The group has indeed produced an analytical analysis done on the shots that, provided it is correct, seems to indicate that the aircraft they observed that night at Edwards is not a B-2 Spirit.

The analysis is based on a stack of 40 separate images, assembled to reduce glare, taken from a distance of over 10 miles.

Here are the reasons why they believe it’s not a B-2.

– The spacing and size of what is assumed could be engine nacelles on either side of the center fuselage.
– Other bumps on the fuselage back that are odd or don’t seem to match the B-2.
– The larger pair of bay doors visible. The B-2 has multiple smaller bay doors for the bomb bay and engine access.
– The seemingly odd landing gear configuration.
– The slender wing section that curves oddly. The B-2’s wing should appear relatively thinker and straight at that view angle.

“Using the ground power unit, sitting next to it, as a measuring metric, (the AF uses Essex B809B-1 units with a 103″ length), we are able to estimate the height of the aircraft at 12.4′ and a wing span of around 130ish’. The B-2 is 17′ and 172′ respectively,” Sammamisham explains. “I also did a view angle comparison to the B-2 which also showed a difference in the wing tip flaps between this aircraft and the B-2. This aircraft was only out during the night hours. We returned the next morning to verify it was or wasn’t a B-2. The aircraft was no longer there (I have pics taken showing it gone). This, in my opinion, also lends credence to it not being a B-2 since it would be odd to pull a B-2 out to do ground tests during the night and early morning hours only.”

Using an Essex BD series power unit as a measuring tool it is possible to roughly determine the dimensions of the aircraft.

Let’s speculate. In fact, what at first glance seems to be a B-2 might really be something else considered we are basing our analysis on a cropped, blurry image taken at night from extreme distance (10 miles). Dimensions aside, there are some details that appear to be quite different from a standard Spirit stealth bomber: obviously we can’t rule out it’s a matter of perspective, objects in the line-of-sight, etc., but the differences in the spacing and dimensions of the engine nacelles (provided they are nacelles) are somehow evident.

The mysterious aicraft appears to be similar to a B-2. But our readers highlighted several alleged differences.

So, assuming the wing span is really 130ish and the aircraft is NOT a B-2 (as mentioned we are just speculating here), what is it?

We have a couple of options here but the one that seems more reasonable given its estimated dimensions, location and operating hours, is that the one depicted in the grainy shots is a secretive B-21 Raider bomber. The next generation long-range stealth bomber is known to be heading to Edwards AFB (so much so a B-21 Combined Test Force patch was already available on eBay months ago) for testing and the concept model of the B-21, has a lot of things in common with the B-2, including the position of the engine nacelles. Based on the B-21 Raider artwork released so far, the aircraft should be much similar to the B-2: the main difference is the “W” shaped trailing edge of the Raider that is an evolution from the Spirit’s sawtooth trailing edge.

Artist rendering of the B-21 Raider. (Wiki/NG)

The B-2’s wingspan is 172 feet, the B-21 has a payload requirement said to be between two thirds and half that of the B-2. That’s why the Raider will probably be lighter featuring a wing span smaller than that of the Spirit.

If you combine all these things and assume the measurements are correct we might be looking at an early Northrop Grumman B-21 article.

The location of the aircraft was: 34.903609, -117.873366
Our reader’s view spot was here: 34.761176, -117.800955

Less likely, it may also be a Northrop Grumman RQ-180.

In the Dec. 9, 2013 issue of Aviation Week & Space Technology, Senior Pentagon Editor Amy Butler and Senior International Defense Editor Bill Sweetman revealed the existence of the RQ-180, a secret unmanned aerial system (UAS), designed for intelligence, surveillance and reconnaissance (ISR) missions, and scheduled to be operational with the U.S. Air Force by 2015.

Developed by Northrop Grumman since 2008-2009, the stealthy RQ-180 is designed to operate in “contested” or “denied” airspace, as opposed to the non-stealthy RQ-4 Global Hawk that are intended for “permissive” scenarios.

In their analysis back then, Sweetman and Butler said: “It is similar in size and endurance to the Global Hawk, which weighs 32,250 lb. and can stay on station for 24 hr. 1,200 nm from its base. The much smaller RQ-170 is limited to 5-6 hr. of operation. […] The aircraft uses a version of Northrop’s stealthy “cranked-kite” design, as does the X-47B, with a highly swept centerbody and long, slender outer wings. Northrop Grumman engineers publicly claimed (before the launch of the classified program) that the cranked-kite is scalable and adaptable, in contrast to the B-2’s shape, which has an unbroken leading edge. The RQ-180’s centerbody length and volume can be greater relative to the vehicle’s size.”

Aviation Week worked with artist Ronnie Olsthoorn to construct concept images of the RQ-180 based on its attributes, including its “cranked kite” design, but these artworks seem to have little in common with what our readers spotted at Edwards.

Nevertheless, considered the quality of the photographs we can’t completely rule out the aircraft is the new stealthy drone that was given a couple of fuselage humps/nacelles similar to the B-2’s.

A pretty famous Northrop Grumman artwork shows an airframe adaptable for bomber and transport roles that was patented in 2012: it bears resemblance to both the B-2 and the X-47B’s shape. If that is the real shape of the RQ-180, then the one at Edwards may well be the new stealthy drone, 4 or 5 of those are believed to be operational somewhere in the U.S.

Northrop Grumman was awarded a patent in 2012 for an airframe adaptable for bomber and transport roles. (Credit: U.S. Patent Office via AW&ST)

That said, let me say that the first time I saw the images I thought it was “just” a B-2 but further observations and Sammamisham’s account have made me a bit dubious. What do you think? It’s a B-2 or something else? Let us know using the comments section below or our Twitter, Instagram or Facebook pages.

Update Aug. 24, 15.30 GMT

Thanks to a Twitter follower (@Kiendl28) we have got a satellite image showing the aircraft on the apron at 18:05Z on Jul. 25. The resolution does not allow a clear identification but the fact the aircraft is parked in daylight seems to suggest there is nothing to hide and points towards the “standard” B-2.

The aircraft on the apron at Edwards at 18.04GMT on Jul. 25. The aircraft can be seen in the same position also on Aug. 11, 12, 13, 14, 15 and 16. (Image credit: PlanetScope).

Image credit: Sammamishman, Zaphod58 and Fred for The Aviationist
