Interesting Photo Shows F-22 Raptor Landing At RAF Lakenheath With Open Missile Bay

This Is Something You Don’t See Too Often.

The photographs in this post were taken by our contributor Alessandro Fucito on Oct. 12, 2017. They show a U.S. Air Force Raptor jet, belonging to the 1st FW, Joint Base Langley-Eustis, Virginia, deployed to the UK, since Oct. 8, landing at RAF Lakenheath with the side weapon bay open.

The stealth multirole jet AF 08-154 is one of the six involved in a FTD (Flying Training Deployment) in Europe. The aircraft have just completed a tour of duty at Al Dhafra airbase, UAE, in support of Operation Inherent Resolve in Syria and Iraq.

Noteworthy, an AIM-9X Sidewinder can be seen inside the open weapon bay.

The F-22 with the open side bays landing at RAF Lakenheath. (Image: Alessandro Fucito).

The latest variant of the Sidewinder missile is a recent addition to the F-22 Raptor inventory: the IR-guided missile has been integrated on Mar. 1, 2016, when the 90th Fighter Squadron (FS) belonging to the 3rd Wing stationed at Joint Base Elmendorf-Richardson, Alaska officially became the first combat-operational Raptor unit to equip an F-22 with the AIM-9X Sidewinder.

Most of US combat planes use the AIM-9X along with a Helmet Mounted Display since 2003 (by the way, one was fired at a Syrian Su-22 recently, but failed for reasons that are still unclear): with a HMD (like the American Joint Helmet Mounted Cueing System – JHMCS), information imagery (including aircraft’s airspeed, altitude, weapons status, aiming etc) are projected on the visor enabling the pilot to look out in any direction with all the required data always in his field of vision. The HMD enables the pilot to exploit the full HOBS (High Off-Boresight) capabilities of the AIM-9X and engage a target by simply looking at it.

However the AIM-9X will not be coupled to a HMD as the Raptor is not equipped with such kind of helmet that provides the essential flight and weapon aiming information through line of sight imagery as the project to implement it was axed following 2013 budget cuts.

In 2019, the Air Force plans to equip the F-22 with the AIM-9X Block II, the F-22 will probably fill the gap as the most advanced variant of the Sidewinder is expected to feature a Lock-on After Launch capability with a datalink, for Helmetless High Off-Boresight (HHOBS) at intermediate range: the air-to-air missile will be launched first and then directed to its target afterwards even though it is behind the launching aircraft.

This will not give the F-22 the same ability as an HMD-equipped aircraft, still better than nothing.

The different AIM-9X envelopes (credit: Hughes via The War Zone)

Back to the top photo, we don’t know the reason why the aircraft flew with an open weapon bay. Although the aircraft can take-off and land with the open side bays, it’s something that happens quite rarely and this leads to believe it might have been because of some sort of system fault that prevented it from being closed.

Salva

Salva

Salva

The U.S. Air Force Turns 70 Years Old Today: A Look Back, A Look Ahead.

USAF Celebrates Its 70th Anniversary With Reverence for History and Hunger for Innovation.

The United States Air Force turns 70 years old today. The newest branch of the U.S. military was born with the passing of the National Security Act in 1947, a restructuring of U.S. military assets in the wake of WWII. During the Second World War air combat operations were conducted by the Marines, Navy and the Army Air Corps.

The U.S. Air Force is arguably the strongest air force in the world, fielding over 5,500 aircraft across different roles. By comparison, intelligence sources cite the Russian Air Force as fielding approximately 3,794 aircraft, the Chinese Air Force claims to operate approximately 3,000 aircraft. All other countries lag significantly behind in numbers and in technology. The USAF is also the only air force in the world to have operational experience with a fifth-generation combat aircraft, the Lockheed Martin F-22 Raptor. The F-22 began flying combat missions in Syria in 2014 and has performed the precision strike, air superiority and intelligence, surveillance and reconnaissance (ISR) roles operationally.

U.S. Air Force F-22 Raptors are providing “kinetic situational awareness” over Syria: the F-22 pilot leverage advanced onboard sensors, as the AESA (Active Electronically Scanned Array) radar, to collect valuable details about the enemy Order of Battle, then they share the “picture” with attack planes, command and control assets, as well as Airborne Early Warning aircraft, while escorting other manned or unmanned aircraft towards the targets. (U.S. Air Force photo by Staff Sgt. Michael B. Keller)

In recent years, the Air Force has received criticism from the general public over pilot shortages and costly acquisition programs like the Lockheed Martin F-35A Lightning II, the Air Force variant of the Joint Strike Fighter. It has also rushed to field an effective ballistic missile defense system for the United States mainland, an effort made more important by concerns over recent advances in North Korean missile capabilities.

The realities of the U.S. Air Force suggest that it is efficient in fielding new programs and cost-effective with assessing developmental programs while simultaneously conducting combat and support operations in several locations around the world. One recent example of the Air Force’s highly adaptive evaluation doctrine is the Light Attack Experiment, a program to evaluate the use of low-cost, already available tactical attack aircraft.

Perhaps one of the most significant advancements has been the establishment of the 24th Air Force as “AFCYBER” or the Air Forces Cyber unit. This operational unit fielded in 2010 provides security, surveillance and combat capability on the rapidly evolving cyber battlefield. The unit is fully operational and regularly performs real-world cyber combat operations in defense of the United States and its allies.

Immediately following the formation of the U.S. Air Force 70 years ago today in 1947 the force began a period of remarkable development programs. The Cold War, a conflict that lasted from 1947 until the Soviet Union collapsed in 1991, was the primary motive for much of the development. This period of remarkable development included advancements like breaking the sound barrier in the Bell X-1 and later achieving the fastest powered atmospheric flight in the X-15.

The Douglas X-3 Stiletto typified the rapid development of experimental aircraft of the USAF in the 1950s. (Photo: USAF)

Later the U.S. Air Force fielded the first operational low-observable or “stealth” combat aircraft with the Lockheed F-117 Night Hawk. The advanced program, that remained classified for years, was also one of the fastest and most cost-effective major acquisition programs in U.S. military history. In fact, there are so many noteworthy Air Force development programs that have set records or created new aviation capabilities they are too numerous to list in a single article.

Even as some superpowers continue to try to achieve technical parity with the U.S. Air Force the USAF continues to innovate with planning for the replacement of the F-22 Raptor, the Next Generation Air Dominance Fighter or “NGAD” and many other new systems.

This is Northrop Grumman‘s concept of the sixth-generation aircraft, known as Next Generation Air Dominance Fighter or “NGAD” fighter jet. (Northrop Grumman)

Considering the U.S. Air Force is the youngest of the armed forces in the United States it is easy to suggest they are the most innovative and have experienced the most change in the last 70 years. Looking ahead to the next century of the U.S. Air Force it’s difficult to envision what it will look like and what its capabilities may be.

Dissecting The Latest Close Encounter Between U.S. F-22 Raptors And Russian Su-35S Flankers Off Alaska

Let’s have a look at what happened in the airspace off Alaska a couple of weeks ago.

On the night of May 3, 2017, two Russian nuclear-capable Tu-95MS Bear bombers, this time escorted by two Su-35S Flanker-E jets, flew again inside the Alaskan ADIZ (Air Defense Identification Zone).

The “mini” package was intercepted by two U.S. Air Force F-22 Raptors some 50 NM to the south of Chariot, Alaska.

The Su-35 is a 4++ generation aircraft characterized by supermaneuverability. Although it’s not stealth, it is equipped with a Irbis-E PESA (Passive Electronically-Scanned Array) and a long-range IRST – Infrared Search and Tracking – system capable, (according to Russian sources…) to detect stealth planes like the F-35 at a distance of over 90 kilometers.

The Su-35S was deployed at Hmeymim airbase, near Latakia in Syria at the beginning of 2016, to provide cover to the Russian warplanes conducting raids in Syria in the aftermath of the downing of a Su-24 Fencer by a Turkish Air Force F-16. During the Syrian air war the aircraft carried Vympel R-77 medium range, active radar homing air-to-air missile system (a weapon that can be considered the Russian counterpart of the American AIM-120 AMRAAM) along with R-27T (AA-10 Alamo-B), IR-guided air-to-air missiles (however, the Flanker E jets escorting the Tu-95s off Alaska, did not carry any weapon.)

Shortly after being deployed to Syria the Su-35S started shadowing US-led coalition aircraft: a German Air Force spokesperson explained that the Russian Flankers were among the aircraft used by the Russian Air Force to shadow the GAF Tornado jets carrying out reconnaissance missions against ISIS; a VFA-131 video that included footage from the cruise aboard USS Eisenhower in support of Operation Inherent Resolve, in Syria and Iraq showed a close encounter with what looked like a Su-35S Flanker-E filmed by the Hornet’s AN/ASQ-228 Advanced Targeting Forward-Looking Infrared (ATFLIR) pod.

Although we have no confirmed reports of “close encounters” between the F-22 and the Flanker in the skies over Syria, what makes May 3 episode particularly interesting is the fact that this was the first time the U.S. Air force Raptors saw the Su-35S near the U.S. coasts.

Moreover, it’s worth noticing the “readiness in flight” posture of the stealth fighters.

Indeed, according to USAF, the Raptors were “committed” by North American Aerospace Defense Command to intercept the Russian aircraft while already in air patrol not too far away. It’s not clear whether the F-22s were already flying because involved in “Northern Edge”, Alaska’s largest and premier joint training exercise with MOB (Main Operating Base) at Joint Base Elmendorf-Richardson, or the CAP (Combat Air Patrol) was one of the measures introduced to enhance the readiness of the U.S. Air Force Air Defense assets as a consequence of the “unprecedented level activity of Russian bombers” recorded in the last months.

Anyway, the American premiere stealth fighters were already flying and thus could be quickly diverted by NORAD to “greet” the Russian package, this time supported by an A-50 Mainstay surveillance plane from distance.

The presence of Mainstay and Flanker confirms what this Author has already explained in the previous report about the key factors to take in consideration when planning a long-range strike sortie.

In my opinion the “mini package” was launched as a consequence of the increased flight activity in Alaska related to the Northern Edge exercise, confirming that the Russians closely observe what happens in the Alaskan area.

This time, they wanted to showcase their ability to plan a complex long-range sortie as well as the Flanker’s readiness to escort its own HVA (high value asset), the Bear, during operations at strategic distance.

The composition of this package is also worth a comment.

The presence of the Mainstay should not be underestimated. It was flying well behind the Flanker and Bear aircraft with a specific purpose. As an AEW (Airborne Early Warning) platform the A-50 is believed to embed some ESM (Electronic Support Measures): in other words, it is able to detect far away targets as well as able to sniff radar, radio and data link emissions. Furthermore, Raptors in QRA (Quick Reaction Alert) *usually* fly with external fuel tanks and Lunenburg lenses: this means that they are (consciously) visible to radars. In such conditions, although it can’t “characterize” the clean F-22’s signature, the Mainstay can at least gather some data about the interceptors’ radar emissions (if any) and observe and study their tactics.

Therefore, as frequently happens on both sides since the Cold War, on May 3, the Russians most probably carried out another simulated long-range strike mission but with a precise ELINT (ELectronics INTelligence) objective: the Flankers and Bears were acting as a “decoy” package to test the American scramble tactics and reaction times, whereas the Mainstay, in a back position, tried to collect as much signals and data as possible about the US fighters launched to intercept them.



Salva

Combined Force of 4 F-15s and 4 F-22s achieves 41-1 kill ratio against 14 “Red Air” fighters at WSEP

A mix of Raptors and Eagles can be pretty deadly, even if outnumbered by enemy fighters.

More than 250 airmen and 9 F-15 Eagle jets from the 104th Fighter Wing, Massachusetts Air National Guard, deployed to Tyndall Air Force Base, Florida, for the Weapons Systems Evaluation Program (WSEP).

Known also as “Combat Archer”, WSEP is an air-to-air exercise hosted by the 53rd Weapons Evaluation Group  to improve air-to-air tactics and practice weapons systems employment: fighter pilots rarely get a chance to fire live missiles, WSEP exercises are almost always the first and only opportunity to use live air-to-air weapons and validate their shots.

“The WSEP does two things,” said Col. Jeffrey Rivers, Commander of the 83rd Fighter Weapons Squadron, Weapons Systems Evaluation Program in a U.S. Air Force release. “It feeds Combat Air Force’s (CAF) training and readiness. We get air crew experience for the first time subsequent to the events, sounds, sights, smells, and noise of a real missile coming off the jet in a realistic scenario they would find normally in training but now it is with real weapons and real targets to shoot at.”

Missiles used in Combat Archer tests usually don’t carry a warhead, replaced by telemetry packages. The AAM are shot over the Gulf of Mexico at various types of drone targets (including the MQM-107D Streaker and the unmanned aerial targets such as the QF-4 recently retired).

During WSEP, the Massachusetts ANG’s Eagle jets flew 212 sorties out of 221 sorties and successfully fired 14,661 bullets at WSEP, totaling 100 percent of the guns on the aircraft firing every time as well as 17 missiles obtaining a mission capable rate of 83%.

“Our deployment to Tyndall really had two different but complimentary themes,” said Col. William Bladen, 104th Fighter Wing, Operations Group Commander. “The WSEP portion focused on exercising and testing the kill chain from the missile build all the way through its destruction of a target. It takes several miracles for a missile to complete an intercept. […] The second piece of the deployment was large force exercises and 4-ship training which is the core fighting force in the Eagle. With several other fighter airframes on the Gulf Coast, we were able to put together daily outnumbered scenarios that we cannot produce up here at Barnes. The last day of the trip we flew 4 F-15s and 4 F-22s against 14 “red air” fighters. For our training, we allowed the red air to regenerate after being killed by a blue air fighter. The final results of that mission: Blue Air killed 41 enemy aircraft and lost just one. While pretty phenomenal, perfection is our goal so the debrief focused on how we could have had a 41-0 ratio.”

Pretty impressive, even though, as always, we don’t know anything about the ROE (Rules Of Engagement), the scenarios, the threat profile, the simulated loadout etc. In this case, we don’t even know the type of adversaries the Eagle/Raptor flight had to fight nor how America’s two premiere fighters cooperated to shoot down all the enemies in the simulated engagements.

Kill ratios attributed to both single types or combined forces always seem to suggest there were direct engagements WVR (Within Visual Range). However, BVR (Beyond Visual Range) aerial combat is probably more likely in future air wars where air dominance has not been clearly established. As proved by what we have witnessed in the Nevada desert during Red Flag 17-2

During WSEP, mixing the deadly ability of the stealthy F-22s to gather, fuse, and distribute information to provide the Counter Air forces with vital situational awareness that could be exploited to engage highly sophisticated aerial threats, with the air superiority capabilities of the un-stealthy F-15s, equipped with powerful Active Electronically Scanned Array (AESA) radars proved to be pretty effective.

As said we don’t know anything about the assets that were defeated during the mock air combat at WSEP. “On the ramp at Tyndall Air Force Base alongside 104th Fighter Wing Eagles, were Canadian CF-18s, F-35s, F-16s, and F-22s,” says the U.S. Air Force release. Some of these might were probably part of the Red Air.

Top image: file photo of a U.S. Air Force F-22 and F-15, 104th Fighter Wing, flying together during Cope Taufan 14 exercise.



All U.S. F/A-18 Hornet models affected by oxygen deprivation and cabin decompression issues

Legacy and Super Hornet showing a concerning steady increase in “physiological episodes” that U.S. Navy calls “No.1 safety issue.”

The F/A-18 Hornets of all variants seems to be affected by a serious issue: oxygen shortage, or hypoxia, is plaguing the fleet of Legacy (A/B/C/D), Super Hornet (E/F) and Growler (EA-18G).

As reported by Bloomberg News, the F/A-18 of all models have shown a steady yearly increases of what the Navy calls “physiological episodes” due to oxygen deprivation and cabin decompression since May 1, 2010.

Navy officials testifying before the House Armed Services subcommittee called the problem the “No.1 safety issue.”

And what is even more concerning is the fact that there seem to be little clue as to what is causing the issue.

The “lack of overall progress” is “of great concern,” said Representative Niki Tsongas, the top Democrat in the panel.

While investigating the issue (with a task force of 62 people), the U.S. Navy has also enhanced “reduced-oxygen training” so that pilots can quickly identify the symptoms of hypoxia. Two aircraft carriers have installed chambers for aircrews exposed to decompression.

According to Bloomberg News, 130 out of 383 episodes “have involved some form of contamination,” according to a Navy and U.S. Marine Corps official statement. 114 involved an environmental control system component failure, 91 involved “human factors” and 50 concerned a component failure with the on-board oxygen generating system.

Older versions of the plane, the A through D models, have problems with cabin pressure whereas the Super Hornet and Growler issues “would appear to point to the onboard oxygen generating” system to which the Navy’ has already made changes.

It’s not clear whether the issue affects also other international Hornet operators.

Not the first time

This is not the first time the U.S. forces face the oxygen deprivation issue.

A similar problem plagued the F-22 Raptor fleet to such an extent the radar-evading aircraft were grounded back in 2011 following a deadly incident involving an Alaska-based stealth jets.

In that period, the F-22 were experiencing 26.43 instances of hypoxia or “hypoxia-like” problems for every 100,000 flight hours, compared to 2.34 instances per 100,000 hours for the F-15E and 2.96 for the latest version of the F-16 (the Hornet was not part of the data set released back then.)

After lifting the flight ban, the Pentagon restricted Air Force Raptors to fly near a “proximate landing location” in order to give pilots the possibility to land quickly if their planes’ On Board Oxygen Generating System (OBOGS) failed.

In May 2012, two 1st Fighter Wing “whistleblowers” appeared on CBS 60 minutes to explain why they were “uncomfortable” flying the Raptor (before changing idea few days later).

The flying branch eventually determined a valve that regulated oxygen flow into the Raptor pilot’s pressure vest was too weak and F-22s were given a new backup oxygen system as part of multiple contracts awarded to Lockheed Martin (worth 30 Million USD) that automatically dispenses oxygen when OBOGS is not providing enough.

Various problems

The news that all the kind of Hornets might be choking their pilots comes in the wake of a Super Hornet and Growler fleet-wide grounding and (concerning but for the moment totally unrelated) increase in crash rate, especially among the oldest models.

Nine incidents involved “Legacy Hornets” (including the Canadian CF-18 lost on Nov. 28, 2016) in the second half of last year, with the latest loss on Dec. 6, 2016, when a USMC F/A-18C crashed off Kochi causing the loss of its pilot.

In the wake of the Hornet crashes from June through October, the U.S. Marine Corps temporarily grounded its non-deployed Hornets. Unfortunately, few days after the ban was lifted, two more F/A-18Cs were lost.

The crash rate has affected the ability of the USMC to perform training activities while committing to support real operations: out of a requirement for 171 aircraft, the service had only 85 Hornets available for training according to a report emerged last year.

In order to address the shortage of operational fighters the Marine Corps has launched a plan to upgrade 30 retired legacy Hornets (currently stored at the 309th Aerospace Maintenance and Regeneration Group at Davis-Monthan AFB, Arizona) to a standard dubbed F/A-18C+: once upgraded these “gap fillers” should be more than enough to conduct combat operations in low-lethality scenarios like those that see the USMC at work lately. Still, they might not have a fix for the hypoxia issue.

“Trump’s favorite jet”

As a side note, in their story on Bloomberg News, Roxana Tiron and Anthony Capaccio call the Hornet “Trump’s favorite fighter jet.”

This is due to the fact that Trump has been advocating the Super Hornet since December 2016, when the then president-elect posted a pretty famous tweet that favored the Boeing combat plane over the Lockheed Martin F-35C.
