A photograph of an Israeli Air Force F-35 flying (more or less..) “over” Beirut has been made public. Interestingly, the image seems to prove the stealthy aircraft was flying with radar reflectors.
As reported yesterday, the Israeli Air Force F-35 stealth aircraft have had their baptism of fire taking part in air strike in the Middle East (Syria and another unspecified “front”) lately. “The Adir planes are already operational and flying in operational missions. We are the first in the world to use the F-35 in operational activity” the Israeli Air Force Commander, Maj. Gen. Amikam Norkin, said during a IAF conference attended by 20 commander of air forces from around the world. Interestingly, Norkin also presented an image showing an IAF F-35I over Beirut, Lebanon that was not released in first place but surfaced on social media on May 23.
The somehow blurry image is interesting for at least a couple of reasons: first of all, it shows the aircraft flying at high altitude off (rather than “over”) Beirut. Second, it seems to show that the aircraft was also operating with radar reflectors (highlighted in the image below), hence not in “stealthy mode”:
Highlighted in a screenshot from Israel Television News Company one of the F-35’s four radar reflectors.
Stealth aircraft, such as the F-22 Raptor or the F-35 Lightning II 5th generation jets are equipped with Luneburg (or Luneberg) lenses: radar reflectors used to make the LO (Low Observable) aircraft (consciously) visible to radars. These devices are installed on the aircraft on the ground are used whenever the aircraft don’t need to evade the radars: during ferry flights when the aircraft use also the transponder in a cooperative way with the ATC (Air Traffic Control) agencies; during training or operative missions that do not require stealthiness; or, more importantly, when the aircraft operate close to the enemy whose ground or flying radars, intelligence gathering sensors.
In fact, tactical fighter-sized stealth aircraft are built to defeat radar operating at specific frequencies; usually high-frequency bands as C, X, Ku and S band where the radar accuracy is higher (in fact, the higher the frequency, the better is the accuracy of the radar system).
However, once the frequency wavelength exceeds a certain threshold and causes a resonant effect, LO aircraft become increasingly detectable. For instance, ATC radars, that operate at lower-frequency bands are theoretically able to detect a tactical fighter-sized stealth plane whose shape features parts that can cause resonance. Radars that operate at bands below 300 MHz (lower UHF, VHF and HF radars), such as the so-called Over The Horizon (OTH) radars, are believed to be particularly dangerous for stealth planes: although they are not much accurate (because lower frequency implies very large antenna and lower angle accuracy and angle resolution) they can spot stealth planes and be used to guide fighters equipped with IRST towards the direction the LO planes might be.
F-35s deployed abroad usually feature their typical four radar reflectors: to exaggerate their real RCS (Radar Cross Section) and negate the enemy the ability to collect any detail about their LO “signature”. As happened during the short mission to Estonia and then Bulgaria, carried out by the USAF F-35As involved in the type’s first overseas training deployment to Europe or when, on Aug. 30, 2017, four U.S. Marine Corps F-35B Lightning II joined two USAF B-1B Lancers for the JSF’s first show of force against North Korea: the F-35Bs flew with the radar reflectors, a sign they didn’t want their actual radar signature to be exposed to any intelligence gathering sensor in the area
The two radar reflectors installed on the right side of the F-35. The other two are on the other side.
Since they almost always fly with the radar reflectors, photographs of the aircraft without the four notches (two on the upper side and two on the lower side of the fuselage) are particularly interesting: for instance, some shots taken on Jan. 24, 2018 and just released by the U.S. Air Force show F-35As deployed to Kadena AB, Japan, in October as a part of the U.S. Pacific Command’s Theater Security Package program, preparing to launch without their Luneberg reflectors.
According to Nir Dvori, the journalist who first published the image of the stealth aircraft off Beirut seemingly flying with RCS enhancers, “they test [the F-35] in all kind of options. Fly with and without reflectors”. Indeed, the use of RCS enhancers would simply mean that stealthiness was not required for that specific mission during which they preferred to hide the aircraft’s stealth features preventing the enemy to collect data about the aircraft and test their radar hardware against the Lightning II. Moreover, the F-35 appears to be flying off Lebanon, accompanied by another aircraft (the photo ship), possibly another F-35 or a completely different type – even a G550 like those that continuously fly off Lebanon and Syria and are trackable by means of their Mode-S transponders. This means that the photo might well have been taken during a simple “recon” mission rather than a combat one. Meanwhile, according to Haaretz’s Anshel Pfeffer:
Not all the missions that the F-35 has so far carried out needed this [stealth] capability. They took part in an airstrike on a Hamas tunnel on the border of the Gaza Strip. Hamas does not have radar, but F-35s were used on this relatively simple mission as part of the process through which its proves it various capabilities. More complex operations against Iranian and Hezbollah targets north of Israel would have utilized its stealth capabilities and some of these did not necessarily involve the F-35 launching missiles itself.
Therefore, it seems confirmed that:
Not all F-35 missions required stealth capabilities
The Adir jets were also used against “easy” targets
The F-35s have taken part in missions during those the Adir did not drop bombs (therefore, it probably acted as “combat battlefield coordinator,” collecting, managing and distributing intelligence possibly sharing targeting data to older 4th Gen. aircraft).
The image seems to prove the F-35 have flown at high-altitude off Beirut (someone says it might have been in international airspace, 12 Nautical Miles from the coast, when the shot was taken, but this can’t be verified based on the screenshot only).
Disclaimer: to our knowledge and based on the sources available on the Internet, those four bumps highlighted in the images you can find in this post are indeed radar reflectors. Several magazines and publications also refer to them as RCS enhancers or Luneberg lenses. Still, if we are wrong and these are EW signal emitters as someone claims, please let us know. Furthermore, the top image is a screenshot from a slide presented during a IAF conference not an actual photograph.
The Israeli Air Force Has Launched World’s First Air Strikes Using The F-35I Adir, IAF Chief Says.
Israel is the first country to have used the F-35 stealth aircraft in combat, the Israeli Air Force Commander, Maj. Gen. Amikam Norkin said on Tuesday, in remarks that were made public through the IDF’s official Twitter account.
According to Haaretz, the Chief of IAF also presented images, that have not surfaced thus far, showing the F-35I over Beirut, Lebanon and said that the stealth fighter did not participate in the last strike in Syria but did in two previous ones.
“The Adir planes are already operational and flying in operational missions. We are the first in the world to use the F-35 in operational activity,” he said.
“The Adir planes are already operational and flying in operational missions. We are the first in the world to use the F-35 in operational activity”
According to local media, speaking at Herzliya conference (held earlier this month) Norkin also said that more than 100 surface-to-air missiles were fired at Israeli jets over Syria.
Whilst the involvement of the F-35 in real missions has been considered “imminent” by some analysts since the Israeli Air Force declared its first F-35 “Adir” operational on Dec. 6, 2017, this is the first time the IAF officially acknowledges, with very little details, the baptism of fire of its 5th generation aircraft.
Indeed, as some journalists have pointed out, it’s not completely clear where and how the F-35s were actually used. Did they strike in Syria and/or Lebanon? What kind of mission did they carry out? Actual air strike (i.e. dropping bombs) or “simple” armed (electronic) reconnaissance?
In the last few months we have observed a series of unconfirmed rumors that the F-35Is had been used to attack Syrian targets. The most recent one, that we completely debunked here, dates back to the end of March, when an alleged IAF F-35 mission into the Iranian airspace was reported by the Kuwaiti Al-Jarida newspaper. According to an “informed source” who had talked to Al-Jarida, two Adir stealth jets flew undetected over Syria and Iraq and snuck into the Iranian airspace, flying reconnaissance missions over the Iranian cities Bandar Abbas, Esfahan and Shiraz.
As reported back then, there were a lot of suspicious things in that story the most important of those was probably the media outlet that broke the news, Al-Jarida, often used to deliver Israeli propaganda/PSYOPS messages. In fact closing the previous article about the “mission over Iran” I wrote:
“The mission over Iran seems […] just a bogus claim most probably spread on purpose as part of some sort of PSYOPS aimed at threatening Israel’s enemies.
Obviously, this does not change the fact that the more they operate and test their new F-35 stealth aircraft, the higher the possibilities the IAF will use the Adirs for the real thing when needed. But this does not seem the case. At least not in Iran and not now.”
Fast forward to today news, the combat debut of the F-35I has been officially confirmed by the Israeli Air Force Chief. With no more details as to where and how the Adir were committed, it’s hard to make any further analysis. For sure, what can be said is that the IAF has proved once again its ability to pioneer combat testing of new aircraft. Although we don’t know the real stategic value of the missions undertaken by the 5th generation aircraft, it’s clear the Israeli have considered the sorties worth the risk. A risk that has become more real on Feb. 10, 2018, when one F-16I Sufa that had entered the Syrian airspace to strike Iranian targets in response to an Iranian drone that had violated the Israeli airspace (before being shot down by an AH-64 Apache helicopter) was targeted by the Syrian Air Defenses and crashed after a large long-range outdated SA-5 missile (one of 27 fired against the jets), hit the Israeli F-16. In that case, in spite the on board warning system of the F-16I alerted the crew of the incoming threat, the pilot and navigator failed to deploy countermeasures.
Although the IAF determined the loss of the Sufa was caused by a “professional error” many sources suggested that the first downing of an IAF jet to the enemy fire since the First Lebanon War could accelerate the commitment of the stealthy F-35Is for the subsequent missions.
What kind of missions? Hard to say. We can’t but speculate here but unless there was some really critical target to hit in a heavily defended airspace, the F-35s might have been initially involved as part of larger “packages” that included other special mission aircraft and EW (Electronic Warfare) support where the Adir jets would also (or mostly) exploit their ELINT abilities to detect, geolocate and classify enemy‘s systems. In fact, along with its Low Observability feature, the F-35 provides the decision makers high-end electronic intelligence gathering sensors combined with advanced sensor fusion capabilities to create a single integrated picture of the battlefield: in other words, not only can the F-35 conduct an air strike delivering bombs but it can also direct air strikes of other aircraft using standoff weapons. The F-35s are known to be able to carry out a dual role: “combat battlefield coordinators,” collecting, managing and distributing intelligence data while also acting as “kinetic attack platforms,” able to drop their ordnance on the targets and pass targeting data to older 4th Gen. aircraft via Link-16, if needed. More or less the same task considered for the USMC F-35B that have flown this kind of missions in exercises against high-end threats in 2016.
Once again it’s worth remembering that along with the inherent risk of flying a combat mission with a brand new technology, as already reported here, the heavy Russian presence in Syria may cause some concern and somehow limit the way the Israeli used or are going to use the F-35 in combat: the Russian radars and ELINT platforms are currently able to identify takeoffs from Israeli bases in real-time and might use collected data to “characterize” the F-35’s signature at specific wavelengths. In fact, tactical fighter-sized stealth aircraft are built to defeat radar operating at specific frequencies; usually high-frequency bands as C, X, Ku and S band where the radar accuracy is higher (in fact, the higher the frequency, the better is the accuracy of the radar system).
Actually as pointed out by Israeli political analyst Guy Plopsky, unlike Haaretz and other local media with English pages, other Israeli media outlets (in Hebrew) quoted IAF chief as specifically stating that the IAF had “struck twice” with the F-35 on “two different fronts in the Middle East“, suggesting IAF Adir may have carried out weapons delivery…
This was later confirmed in an official post on the IAF website: “We performed the F-35’s first ever operational strike. The IAF is a pioneer and a world leader in operating air power”.
Anyway, let’s wait and see if other details emerge. For the moment let’s just take note of the first officially-confirmed combat use of the controversial F-35 Lightning II.
Last night the Israeli Air Force attacked dozens of Quds force targets in Syrian territory. This video shows what seems to be a Delilah cruise missile hitting a Pantsir-S1 (SA-22 Greyhound) surface-to-air missile and anti-aircraft artillery weapon system. Warning: graphic footage.
“On May 9, 2018, the Quds force, a special force wing of the Iranian Revolutionary Guard, stationed in Syria, shot 20 rockets towards IDF posts in the Golan Heights. The IDF intercepted four of the rockets, preventing casualties and damage. This is the first time that Iranian forces have directly fired at Israeli troops.
In response, in the night on May 10, IDF fighter jets (mainly F-16I Sufa aircraft according to most sources even though the official IAF website’s release on the attack shows also a file photo of an F-15I) struck several military targets in Syria that belonged to Iran’s Quds force. “The IDF’s wide-scale attack included Iranian intelligence sites, the Quds force logistics headquarters, an Iranian military compound in Syria, observation and military posts, et cetera. In spite of a warning from Israel, Syrian aerial defense forces fired towards the IAF aircraft as they conducted the strikes. In response, the IAF targeted several aerial interception systems (SA5, SA2, SA22, SA17) which belong to the Syrian Armed Forces. All of the IDF’s fighter jets returned to their bases safely.”
An illustration showing the targets hit by the IAF on May 10. (image credit: IDF)
Among the targets hit by the Israeli combat planes there is also a Pantsir-S1 (SA-22 according to the NATO designation) as shown in the following footage.
The Pantsir-S1 is a Russian-built advanced, self-propelled combined gun/missile system that is made mobile on 8×8 trucks. The transportable gun/SAM system includes up to 12 surface-to-air missiles arranged into two 6-tube groups on the turret, and a pair of 30mm cannon.
The SA-22 was destroyed from what, based on the type of aircraft reportedly involved in the air strikes, the range of the missile and similar footage available online, seems to be a Delilah missile (actually, there is someone that suggested the missile might have been a Spike NLOS, but the use of a standoff missile seems much more likely).
The Delilah missile on an F-16I Sufa (image: Wiki)
The Delilah is a cruise missile developed in Israel by Israel Military Industries (IMI), built to target moving and re-locatable targets with a CEP of 1 metre (3 ft 3 in) at a maximum range of 250 km.
The best description of the cruise missile comes from the IAF website:
In terms of its structure, the Delilah is almost identical to a typical air-to-ground missile. The front section includes the homing parts, which in the first models were televisional. Thus, the head of the missile includes an antenna for general guidance towards its target. The next section holds the various electronic parts including guidance systems and flight control. The part behind this holds the warhead and fuel supply. The final section is made up of a jet engine capable of producing 165 pounds of thrust and the control surfaces that turn the missile towards its target.
Examining the technical data alone raises the question of why the Delilah is considered such an important missile. After all, there are missiles capable of flying further and faster and carrying warheads many times larger which are available on the global weapons market. The answer lies in the fact that the Delilah is seen more as a “loitering missile” than a cruise missile.
In general typical air-to-ground missiles are launched in the general direction of their target. A navigational system (such as GPS) takes them to the spot where intelligence indicates that the target lies. If the missile is autonomous (“fire and forget”) then the plane that launched it can simply leave. The missile flies towards the target. When it identifies it, it strikes it with the help of its final guidance system. When the target is not where it is expected to be, the missile is simply written off. An example of this sort of weapon is the US Tomahawk missile, at least in its early models.
When a missile is fitted with an electro-optic guidance system, it broadcasts an image of what is in front of it, back to the aircraft that launched it. The image from the homing device is shown on a special screen in the cockpit, usually facing the navigator’s chair in a two-seater aircraft. The navigator can send the missile instructions, and make small changes in its flight path. However, these changes can only take pace during a relatively short period of time, and are comparatively minor. From the moment that the missile begins its final approach, no changes can be made. The result is that although he has some control, the navigator is actually very limited. If a missile approaches a target, which at the last minute turns out to be moving, or the wrong target altogether, then the missile misses. Thus, there have been many events like the one in Yugoslavia in 1999 when an electro-optic bomb launched from a US combat airplane was launched at a bridge. Seconds before impact, a passenger train reached the bridge and all the navigator could do was watch in horror, knowing that many civilians would be killed. It is here that the Delilah’s unique ability enters the picture.
[…]
The Delilah’s operation is similar to what is described above; it, too, possesses a “Man in the Loop” mechanism, where the navigator controls the final direction of the missile. However, in the case of the Delilah there’s a key difference: as the missile makes the final approach, if the target has moved or if there’s a need to cancel the attack (for example, if civilians are spotted near the target), all the navigator needs to do is press a button in the cockpit which instructs the missile to abort its approach and return to linger. Thus, situations in which a missile is wasted on a target that has disappeared, or in which civilians are accidentally killed can be prevented. In the same way the use of a missile on a target that has already been destroyed can be prevented, saving valuable ammunition.
This is not the only value in the Delilah missile’s ability to linger. One can imagine a situation in which the target’s precise location is not known with any certainty, for example if it is a portable anti-aircraft launcher or land-land missile launcher. In this case the Delilah can be launched in the general direction of the target, based on intelligence reports. The missile would fly in the direction of the target, all the while surveying the territory with its homing equipment. The image appears in the cockpit, the Delilah serving effectively as a homing UAV. The Delilah patrols above the territory searching for its target. The missile’s long range can be exchanged for a prolonged stay in the air above the target. When the navigator identifies the target, or what is thought to be the target, he instructs the missile to fly towards it. If he has identified it correctly then the missile is directed to attack it. If he has not found the target then the missile is instructed to abort its approach and return to searching.
The Delilah missile’s ability to both loiter and carry out repeated passes makes it the ideal weapon for attacking mobile sites like rocket launches. Everyone recalls the difficulty the US Air Force faced during the 1992 Gulf War when it attempted to locate and destroy the Iraqi “Al-Hussein” rocket launcher that was used to fire at Israel and Saudi Arabia. The Americans knew roughly where the rockets were being launched from but had difficulty locating the launchers themselves. As a result fighter planes were sent for long patrols over western Iraq every night. On many occasions the Americans identified the point where the missile was launched from, but by the time a counter-strike had been arranged the missile launcher had left the scene. It’s in these sorts of operational profile that the Delilah performs best, perhaps better than any other weapons system. In these cases the Delilah can be launched towards the area intelligence expects the missiles to be launched from. The Delilah will fly above the area and search for missile launchers. When a launcher is identified, it will be immediately struck by the missile. If it’s discovered that the target has not been identified correctly, for example if it’s a dummy launcher or another vehicle that looks like a launcher (such as a petrol tanker), the missile receives the instructions to end its approach and continue to search for the real target.
“The Delilah is a system that can strike very precisely at critical, sensitive points from a great distance”, explains Brigadier General (reserve) Arieh Mizrachi, who was once CEO of IMI.”If we want to attack a command bunker, for example, and we know where it is situated and exactly which window we need to hit then we can do it. We can always make another approach and place the missile exactly where we want it. The extreme precision of the missile makes it possible for us to paralyze the enemy by striking their critical point. For example, if we send the missile through a window of a division’s control center, then no one will be left to give orders, and we’ll have silenced the whole division. It’s important to understand that the target does not need to be a large command center. The ‘Delilah’ lets us strike at the brain of the enemy, even if it’s a small mobile target like a command armored personnel carrier. Similarly, we can strike at a ship’s command center without needing to sink the whole ship. This holds true for many other kinds of target like airports, logistics centers and so on. The moment we identify the critical point, the Delilah lets us hit it”.
[…]
“The training needed to operate the Delilah lasts a few months, and because of its complex capabilities, not everyone successfully completes it”, explains First Lieutenant A., an F-16D navigator in the “Scorpion” Squadron who is trained on the Delilah. “The training process is long, complex and challenging. You start with simple scenarios, hitting a large target in open space, and advance to small targets that are located in densely populated areas”.
“Despite the intense cooperation between the pilot and the navigator, the fact remains that the missile is operated from the navigator’s cockpit. In the first stage you launch the missile and it flies towards the target you’ve given it. Later in the flight, you take control of the missile and direct it wherever you want. If you need to, you can press a button and the missile will loiter. The role of the pilot is to tell me when I’ve reach the point where I need to tell the missile to fly, and I can no longer tell it to continue to loiter”.
“Even though you are not physically in the same place as the missile, and in fact are far away, the whole time you feel that you are part of it. The fact that you can fly the missile wherever you want, whilst you yourself fly to an area that is not under threat, gives you safety”.
Anyway, here’s the footage:
As said, the Delilah is a standoff weapon: it means the aircraft can use it while remaining at safe distance.
As a side note, according to our sources, a KC-707 tanker that supported the F-16I. Yesterday, more or less when the jets were attacking the targets in Syria, a KC-707 was operating in the southern part of Israel.
We can’t be sure the tanker was supporting the raid (the fact an Israeli aircraft could be tracked online during a combat mission is somehow surprising), still worth a mention.
This revised chart provides a good overview of the assets that took part in the Trilateral strikes on Syria last month.
As our readers already know, in the night between Apr. 13 and 14 the U.S., UK and France launched air strikes against Syria. By means of an OSINT analysis, we were able to determine the presence of most of the aircraft which took part in the operation, most of those could be tracked online via information in the public domain, hours before their involvement was officially confirmed.
Based on the “picture” we have contributed to build up, the popular one-man site CIGeography has prepared an interesting chart to visualize the type and number of the assets that have taken part or supported the strike. Although this is a revised version of an original chart posted on Apr. 29, it still contains some inaccuracies: for instance, just 6 out of 8 French C-135FR tankers are shows; at least 11 US tankers supported the American aircraft at various times; two RQ-4s are shown in the chart although we have tracked just one example [#10-2043 – a serial that is still subject to debate] and no other Global Hawk is known to have been committed, etc. Moreover, little is known about the aircraft that operated from the UAE and Qatar bases (including the EA-6B Prowlers, known to have supported the B-1s) and whose presence and number could not be determined by means of online flight tracking; still, it represents the only available chart that summarizes the types, the airbases and the weapons used to attack Syria last month.
Make sure you follow @CIGeography on Twitter and Facebook. You can also buy one of the posters based on this and other charts CIGeography has produced here.
A Swedish Air Force heavily-modified Gulfstream IVSP aircraft used to perform ELINT (Electronic Intelligence) missions has joined the long list of ISR (Intelligence Surveillance Reconnaissance) platforms operating in the eastern Mediterranean Sea.
On May 1, 2018, a Swedish Air Force S102B Korpen has started operating in the eastern Med.
The aircraft is one of two SwAF’s S102B Korpen aircraft, heavily-modified Gulfstream IVSP business jets used to perform ELINT missions. These aircraft have been in service with the Swedish Air Force since 1992, when they have replaced the two TP85s (modified Caravelle airliners formerly belonging to the SAS airline) that had been operated for 20 years since 1972. They are equipped with sensors operated by ELINT personnel from the FRA (the Radio Establishment of the Defence), capable to eavesdrop, collect and analyse enemy electronic emissions. As we have often reported here at The Aviationist, the Korpen jets routinely conduct surveillance missions over the Baltic Sea, flying high and fast in international airspace off the area of interest. The most frequent “target” of the S102B is Kaliningrad Oblast and its Russian installations. For this reason, the Swedish ELINT aircraft are also frequently intercepted by Russian Su-27 Flankers scrambled from the Kaliningrad exclave’s airbases.
Anyway, it looks like the Swedish airplane has now pointed its sensors to the Russian signals in Syria, deploying to Larnaca, Cyprus: the example 102003/”023″, using callsign “SVF647”, was tracked, by means of its ADS-B/Mode-S transponder, twice on May 1, flying off Syria, Lebanon, Israel and Egypt, more or less in the very same way many other aircraft (U.S. Navy P-8s, U.S. Air Force RQ-4 and RC-135s) have been doing for some weeks.
Considered the quite unusual area of operations, one might wonder why the Swedish S102B is currently operating close to the Syrian theater, so far from home. We can just speculate here, but the most likely guess is that the aircraft is collecting ELINT off Syria to acquire new baseline data for assets that are deployed there and which may either be currently or imminently deployed in Kaliningrad. Possibly surface vessels too, which might add to the Baltic Electronic Order of Battle. “I think they are just acquiring ELINT that is unique to Syria and might have applications in the Baltic,” says a source who wishes to remain anonymous.
For sure, with all the Russian “hardware” deployed to Syria, often referred to as a “testbed” for Moscow’s new equipment, there is some much data to be collected that the region has already turned into a sort of “signals paradise” for the intelligence teams from all around the world.
Top image: Peter Bakema/Wiki and @ItaMilRadar
