Here’s The Video Of The Syrian Su-22 Fitter Being Shot Down By A U.S. Navy F/A-18E Super Hornet

F/A-18E Super Hornet vs Su-22 Fitter near Raqqa, as seen through the Hornet’s ATFLIR.

On Jun. 18, F/A-18E Super Hornet belonging to the VFA-87 “Golden Warriors” and piloted by Lt. Cmdr. Michael “Mob” Tremel,” shot down a Syrian Arab Air Force Su-22 Fitter near the town of Resafa (40 km to the southwest of Raqqa, Syria).

The VFA-31 Tomcatters, also embarked on USS George Bush (CVN-77) supporting Operation Inherent Resolve from the Mediterranean Sea back then, have included footage of the aerial engagement, filmed with their ATFLIR (Advanced Targeting Forward Looking Infra Red) pod, in their 2017 OIR cruise video.

Here below you can see the relevant part of the cruise video, the one that shows the AIM-120 AMRAAM (Advanced Medium Range Air-to-Air Missile) hitting the Syrian Sukhoi (from two different angles – maybe because other Hornets filmed the scene) and then the Fitter crashing into the ground.



The Massive U.S. Military Response to Hurricane Harvey in Texas; On Alert For Irma In Florida.

Aircraft, Rescue Personnel and Ships Respond to U.S. National Emergency.

The U.S. military has fielded a massive rescue and relief operation in the wake of Hurricane Harvey along the Texas coast. News media and military sources report “more than 1,000 active-duty troops” will provide rescue and relief operations to the region, with an additional 1,100 prepared to deploy, according to the Department of Defense.

The initial U.S. military response to Hurricane Harvey included the Coast Guard and Texas National Guard. As the scope of the storm grew additional active-duty units, including significant air assets, from across the U.S. were put on alert and then tasked with rescue and support operations in the storm-stricken region.

“Approximately 1,600 active-duty military personnel are deployed to the affected area,” US Northern Command, who controls active duty U.S. military personnel in North America, said in a statement to media on Thursday, August 31.

The U.S. military’s Northern Command located at Peterson AFB in Colorado Springs, Colorado has directed the deployment of 73 helicopters, mostly various versions of Blackhawks, 4 Lockheed C-130 cargo aircraft and 8 elite Air Force Para-Rescue units to support aid and rescue operations in the region. The units come from locations around the United States.

Media outlets including CNN have reported that the Air Force has flown rescue/relief missions using “Seven HC-130 Combat King IIs, four C-130 Hercules, 11 HH-60 Pavehawks, five C-17 Globemaster IIIs, one E-3 Sentry AWACS, one E-8 JSTARS and one KC-10 Extender.” Additional reports have indicated at least one U.S. Navy P-8A Poseidon surveillance aircraft has joined the operation.

USAF Pararescue operators, special operations aviators and crewman return from a rescue mission on August 29, 2017 to Easterwood Airport in College Station, Texas. The mission rescued 11 people from the flooded area in a single sortie. The aircraft from the 347th Rescue Group of Moody AFB, Georgia were deployed in support of FEMA during Hurricane Harvey. (USAF Photo by SSG. Ryan Callaghan)

As of yesterday there have been a reported “4,700” aerial rescues conducted by military assets in the region. Because of the size of the military air relief effort, airports in the region are filled to capacity with aircraft assisting in the search and rescues.

The U.S. Navy dispatched the vessels USS Oak Hill (LSD-51), a Harpers Ferry-class dock landing ship and the Wasp-class amphibious assault ship USS Kearsarge (LHD-3) to the Gulf region in support of humanitarian aid and rescue operations. The USS Kearsarge is equipped with a flight deck to support helicopter and tilt-rotor flight operations and has a waterline level stern well deck for deploying surface craft including large assault landing hovercraft.

The USS Kearsarge (LHD-3) has been deployed to the Texas gulf coast in support of humanitarian aid operations in the region. (USN Photo)

Depending on the source, approximately 66 people have reportedly lost their lives so far in Hurricane Harvey, a relatively low number in part due to effective early warning and evacuation but also partially because of a very large U.S. military response to the crisis. This casualty figure, while very significant, contrasts with the approximately 8,000 lives lost in the Galveston, Texas hurricane at the turn of the century in 1900. That hurricane happened before accurate weather prediction, advanced communication and rescue resources existed.

The gigantic tropical storm, that began on August 17 and continued until September 2, was the first storm of its type to hit the U.S. mainland since 2005 when Hurricane Wilma landed. Sustained winds in excess of 100 MPH and the worst flooding ever recorded in the history of the region caused widespread destruction. The city of Port Arthur, Texas is one of several cities that remain completely submerged following the storm, with even their evacuation centers becoming flooded necessitating the relocation of rescued people initially placed there by aid workers. In some areas floodwaters, the worst ever, did not reach their highest point until days after the storm.

Another tropical storm in the region, Hurricane Irma, is forecasted to make landfall in Florida this Saturday. Satellite surveillance on Wednesday measured the storm as over twice the width of Florida. Airborne weather reconnaissance and sea-based data collection have measured sustained wind speeds of 195 MPH in the approaching storm as the U.S. hurricane season continues.

The National Oceanic and Atmospheric Administration, NOAA, has flown weather reconnaissance missions into the rapidly approaching Hurricane Irma off the Florida coast using their newly upgraded and repainted Lockheed WP-3D Orion N42RF, named “Kermit”. The aircraft has operated from Tampa, Florida. The crew captured dramatic video of one of their weather reconnaissance missions. During the flight the aircraft dropped a series of parachute-deployed NCAR GPS Dropsonde airborne sensors. The small sensors fall gradually through the hurricane suspended by their parachute and collect wind velocity and directional data. Once a pattern of dropsonde sensors are released into the storm by the WP-3D aircraft they transmit data from their wild ride through the storm back to monitoring stations to provide intelligence about the storm’s direction, strength and speed.

The National Oceanic and Atmospheric Administration operates two hurricane surveillance Lockheed WP-3D Orions from Florida to gather weather intelligence from upcoming storms like Hurricane Irma scheduled to land in Florida this weekend. (NOAA Photo)

At this link you can find the daily schedule of the NOAA aircraft activity for today.

The NOAA aircraft mission plan for Sept. 7, 2017.

Salva

Salva

Up Close And Personal With Textron’s Scorpion Light Attack Jet During Weapons Separation Testing

Textron’s Scorpion Aces Weapons Separation Testing.

Going five for five in the complex, methodical and engineering-driven military aircraft test regimes is rare. Weather, range logistics, recording equipment, aircraft readiness or one of any other number of details typically conspire to scrub a test flight.

This past July the Textron Aviation Defense Team of two Scorpion jets (production airframes P2 and P3), three Test Pilots, two Flight Test Engineers and 12 support staff (ground, weapons, maintenance, program) descended on NAS Patuxent River, Maryland for weapons separation testing. Five scheduled flight tests in five different configurations over five flight days with 100% completion on time and target enabled the team to achieve “Ace” status, of sorts.

The test plan was aggressive and put the credibility of the three Textron test pilots at risk – all graduates of the US Navy Test Pilot School at Pax River.

Textron Aviation’s Scorpion Jets form up in the skies over Wichita, Kansas. The four Scorpions (developmental aircraft in the foreground with production aircraft 1-3 ) are maintaining heavy utilization rates expanding the flight envelope, performing weapons testing, making demonstration flights to a variety of interested customers and participating in the USAF light attack experiment.

Textron Chief Test Pilot Dan Hinson (23 years in the F/A-18) was humbled to be back among the professionals where he had served and honed his skills. Hinson noted the tremendous respect for both NAVAIR and the Navy’s VX-23 developmental flight test organization, the Air Test and Evaluation Squadron affectionately known as the “Salty Dogs.” The entire test regime was carefully coordinated with NAVAIR, the Naval Test Wing Atlantic (NTWL) and VX-23 with protocols followed in the same fashion as is done for military aircraft tests.

Textron Scorpion fires 2.75″ Hydra-70 rockets during recent weapons trials at NAS Patuxent River, MD. The Textron team achieved 100% mission completion rate during weapons system testing. 5 different configurations (LAU-131, HMP-440 Gun pods, GBU-12) were tested over 5 days, with the tests concluding 4 days early.

Weapons separation may appear simple; however, it is complex testing that is rigorously documented. One Scorpion functioned as “chase“ aircraft while the “tester” was outfitted with high speed cameras on the nose, wing and tail. Every aspect of the release was closely monitored with scores of data points captured.
This was the first time the Scorpion had achieved rack separation. Weapons such as the HMP-400 .50 Cal guns and LAU-131A/A rocket launcher were monitored for hot gas ingestion into the intakes. Operational modes were tested and wiring configurations were evaluated.
Weapons tested included:

  • LAU-131A/A 2.75” unguided/guided rocket launcher
  • HMP-400 .50 Cal machine gun pods, (two flights with single and simultaneous firing)
  • GBU-12 Paveway II 500 lb. bombs
  • BDU-50 (500 lb. practice bomb)

As aggressive as the schedule for the weapons testing was, it was completed four days early. Hinson and team relished the tremendous professional support of NAVAIR, NTWL and VX-23 and departed with the Navy’s great respect for their test efficiency and rigor, fortified. The completed tests took place just in time to open the weapons delivery envelope in support of the USAF OA-X Light Attack Experiment taking place at Holloman AFB, New Mexico.

Textron Scorpion drops a 500 lb GBU-12 Paveway II during recent weapons trials at NAS Patuxent River, MD. The Textron team achieved 100% mission completion rate during weapons system testing. 5 different configurations (LAU-131, HMP-400 Gun pods, GBU-12) were tested over 5 days, with the tests concluding 4 days early.

The aircraft utilized for testing were of the production standard (P1-P3) differing from the original developmental aircraft (D1) in the following ways;

  • P1-P3 all feature an all trimmable tail – enabling improved flight performance.
  • The large internal payload bay has been reconfigured to house deeper payloads.
  • The landing gear has been updated to a trailing link gear configuration with larger brakes.
  • P1-P3 utilize a full Garmin G3000 Avionics suite.

Given all the attention the attack component of the Scorpion has received in the press, it is often overlooked that the aircraft is built around a payload bay. The modular payload bay is impressive with great volume, electrical and cooling capacity for a wide variety of payloads/sensors. One example is the L-3 Wescam MX-25 – now capable of full retraction into the payload bay. The MX-25 is L-3 Wescam’s largest electro-optical/infrared camera. For comparison purposes, the US Navy P-8 Poseidon utilizes the slightly smaller L-3 Wescam MX-20.

Textron Scorpion with HMP-400 gun pods overflies NAS Patuxent River during recent weapons trials. The TEXTRON team achieved 100% mission completion rate during weapons system testing. 5 different configurations (LAU-131, HMP-400 Gun pods, GBU-12) were tested over 5 days, with the tests concluding 4 days early.

Aside from great payload flexibility, the Scorpion is night vision capable and both the front and rear cockpits are prepared for use with the Thales Visionix Scorpion Helmet Mounted Cueing System.

Textron’s Scorpion summer of 2017 has been a resounding success. The 4 aircraft (D1, P1, P2, P3) were simultaneously tasked at multiple locations (Paris International Airshow, Royal International Air Tattoo (RIAT – RAF Fairford), Pax River, MD [weapons testing] and the ongoing USAF OA-X Light attack experiment. All while a production airframe (at times two) continued with envelope expansion testing at Textron’s base in Wichita, Kansas.

Textron Scorpion fires 2.75″ Hydra-70 rocket during recent weapons trials at NAS Patuxent River, MD. The Textron team achieved 100% mission completion rate during weapons system testing. 5 different configurations (LAU-131, HMP-440 Gun pods, GBU-12) were tested over 5 days, with the tests concluding 4 days early.

In a class by itself, the Scorpion offers unique capability to carry the latest ISR sensors, loiter for extended periods of time and prosecute targets at will. Given the aircraft’s sound performance to date, the Scorpion appears well on the way to becoming the solution of choice for economical, intelligent and lethal airpower in the permissive environment or as a component of a large force projection.

Textron Scorpion fires 2.75″ Hydra-70 rocket during recent weapons trials at NAS Patuxent River, MD. The Textron team achieved 100% mission completion rate during weapons system testing. 5 different configurations (LAU-131, HMP-440 Gun pods, GBU-12) were tested over 5 days, with the tests

The Author expresses special thanks to Dan Hinson – Textron Aviation Defense Chief Test Pilot and former NAVAIR PMA-265 F/A-18 & EA-18G Integrated Product Team Lead, Commanding Officer of the U.S. Naval Strike Fighter Weapons School, and graduate of U.S. Naval Test Pilot School Class 103.

Photo Credits, as indicated US Navy by Erik Hildebrandt / Released and Jim Haseltine / Released

U.S. Commissioning New Class of Supercarrier, USS Gerald R. Ford (CVN-78) Tomorrow

UK, China and U.S. Launch New Carrier Classes in 2017, Russia Lags Behind.

The U.S Navy and Newport News Ship Building Company officially commissioned a new class of “supercarrier” advanced nuclear-powered aircraft carrier tomorrow at the Norfolk Naval Station in Norfolk, Virginia.

The USS Gerald R. Ford (CVN-78) is the first ship in this new class of nuclear-powered aircraft carriers for the U.S. Navy. It is the first major redesign of U.S. aircraft carriers in 42 years.

Among a long list of new engineering features on board USS Gerald R. Ford are the controversial electromagnetic catapults and arresting gear, a new, smaller, lower radar cross section island structure, larger and more efficient flight deck facilitating faster aircraft launching, more than twice the electrical power of previous carrier classes and a more efficient crew compliment with 500 fewer personnel on board. The massive 1,106-foot-long carrier displaces a staggering 100,000 tons fully loaded and is powered by two new generation nuclear reactors.

U.S. President Donald Trump has been critical of the costs of the program, especially the new electro-magnetic catapult and arrestor take-off and landing systems. The benefits of the new systems are claimed to be less buffeting of aircraft upon launch resulting in better control and less airframe fatigue per launch and recovery. The electromagnetic catapults are also lighter in weight than steam catapults in use on current U.S. carriers and are claimed to require less maintenance than steam-powered launch and recovery systems.

It’s worth noting that some problems have already occurred in launch testing on other carriers with the U.S. Navy’s version of the F-35 Joint Strike Fighter, the larger wingspan, folding wing F-35C. The problems may have been limited to test launches with no weapons loads and required modifications to F-35C landing gear. Depending on the status of these issues the Navy’s F-35C may benefit in particular from electromagnetic catapults.

CF-03 FLT 182/CF-05 FLT 91 First Arrestment aboard USS Nimitz on 03 November 2014. CDR Tony Wilson was flying CF-03 and LCDR Ted Dyckman was flying CF-05.

This year has been noteworthy for new international aircraft carrier operations.

On Jul. 17, 2017, the Royal Navy launched the first of its new Queen Elizabeth Class of aircraft carrier. The HMS Queen Elizabeth (RO8) is the first of two carriers in this new class that will include the second vessel, the HMS Prince of Wales (RO9) when it is launched in 2020.

HMS Queen Elizabeth uses non-nuclear electric propulsion that burns primarily diesel fuel. This is a lower cost alternative to the U.S. nuclear powered carrier. HMS Queen Elizabeth is a smaller carrier than its new U.S. counterpart, and intended to operate with a compliment of thirty-six F-35B V/STOL aircraft and four helicopters. The vessel is currently configured without launch catapults, but is engineered to be “backwards and forwards compatible” for retrofitting of a catapult launch system. The vessel is also smaller than its U.S. counterpart, the new USS Gerald R. Ford. The HMS Queen Elizabeth is 920 feet long compared to the USS Gerald R. Ford’s 1,106 foot length. It also displaces “only” 70,600 tons compared to the Ford’s 100,000+ tons of displacement.

A Royal Navy Merlin helicopter was the first aircraft to fly from the deck of the England’s new HMS Queen Elizabeth. (Photo: Daily Telegraph)

The Chinese have also been vigorous in their carrier development program with the recent launch of the impressive Type 001A, their first indigenous construction carrier. Previous Chinese aircraft carriers were purchased second-hand, mostly from Russia, and served primarily as development testbeds for aircraft, crews and likely doctrine.

This first domestically built Chinese carrier, likely to be named “Shandong”, was officially launched in Dalian, Liaoning province, on Apr. 26, 2017. The Type 001A “Shandong” uses a ski-jump style launch system and an arrestor cable recovery.

A Chinese J-15 makes an arrested landing on the carrier Liaoning. (Photo:USNI)

There have been recent photos of Chinese J-15 aircraft with updated landing gear that is both reinforced for carrier landings and, most interestingly, a catapult bar on the nose wheel. The new version of the J-15, referred to frequently as the “J-15A”, is considerably reworked to include not only the landing gear modifications but new engines and avionics.

A new version Chinese J-15A appeared with catapult launch capable landing gear. (Photo: Chinese Media)

A Jul. 6, 2017 report filed on Chinese media reported that the Chinese People’s Liberation Army Navy, or “PLAN”, is conducting land-based testing on a new electromagnetic catapult similar to the one already installed on the new U.S carrier Gerald R. Ford.

Satellite images showing a land-based catapult launch test facility at Huangdicun Airbase in Liaoning Province, China. The U.S. Naval Institute, an intelligence publications resource, reported that satellite imagery showed two types of catapults located at the Huangdicun facility beginning in late 2014, one steam and one electromagnetic. This base also houses China’s J-15 aircraft on land.

Finally, with news of new aircraft carriers from the United States, China and England an assessment of Russia’s current aircraft carrier capabilities suggests they are lagging behind.

Russia deployed its only carrier, the Admiral Kuznetsov, to the eastern Mediterranean in fall of 2016 in support of operations in Syria. The results could accurately be described as “mixed”.

Kuznetsov, an old ship originally launched in 1985, lost two if its only fifteen aircraft to accidents including an embarrassing one when one of Russia’s most experienced pilots was forced to ditch his aircraft next to the carrier due to problems onboard that prevented him from landing. He was ordered to hold in the landing pattern so long while addressing the onboard recovery problem that his aircraft eventually ran out of fuel. The pilot ejected next to the carrier and was recovered. The aircraft was one of two lost on the Russian adventure to the Mediterranean in support of the President Bashar al-Assad regime in Syria.

The Admiral Kuznetsov has had previous problems on its only seven deployments since 1990.

In 1996, the ship’s potable water distillation system failed and, embarrassingly for the Russians, the U.S. Navy came to the aid of the vessel, supplying fresh drinking water to the crew.

Back in 2015 Russia announced insights into a proposed new, very large aircraft carrier class in the 100,000 ton “supercarrier” range. Russian Deputy-Director of the Krylov State Research Center told IHS Jane’s that the project was being called “Project 23000E” or “Storm”. Budget constraints, Russia’s support of the war in Syria and economic concerns have all but cancelled progress on the project. The most recent intelligence suggests Russia was attempting to partner with India to share development costs in the hopes of India eventually acquiring one of the new class of proposed Russian supercarriers for its own navy.

Russia’s carrier Admiral Kuznetsov is beginning to show its age. (Photo: RT)



Salva

Salva

This Footage *Allegedly* Shows A Russian MiG-31 Shooting Down A Cruise Missile In The Stratosphere.

According to the Russian MoD this video shows a Russian MiG-31 Foxhound taking down a cruise missile.

According to the press center of the Pacific Fleet of Russia, a Russian Navy MiG-31 Foxhound interceptor launched from the Kamchatka Peninsula, intercepted a supersonic cruise missile in the stratosphere during exercises that were conducted on the eve of the celebration of the Day of Naval Aviation.

The missile was launched from the water area of the Sea of Okhotsk at an altitude of more than 12 kilometers at a speed three times the speed of sound, Pravda new outlet reported.

The Mig-31 Foxhound is a two-seat Mig-25 Foxbat derivative in service since 1983.

Whilst the MiG-25 was built as a high-speed, high-altitude interceptor, capable of reaching the speed of Mach 3.2 to intercept American B-58 and B-70 bombers, the MiG-31 was designed to intercept the B-1B bomber, which was designed to operate at low-level, below the radar coverage.

The MiG-31 has quite good low-level capabilities (which MiG-25 does not) and is equipped with an advanced radar with look-down-shoot-down capability (needed to detect low-flying bombers), and data bus, allowing for coordinated attack with other fighters.

The production of the Mig-31, one of the world’s fastest tactical fighter in active service with top speed of Mach 2.83 and a range of 1,450 km, ended in the early 1990s, but the interceptor is being upgraded to extend its operative life up to the 2028 – 2030.

The Russian MiG-31BM jet, capable to carry up to four long-range R-33 missiles and four short-range R-77 missiles, was expected to carry a weapon able to shoot down space satellites; according to some sources, the ability to intercept a cruise missile, previously Kh-55 and now Kh-101, is something practiced by the Russian Foxhounds for years.

The video below, released by the Russian MoD, is said to show the test conducted on Jul. 17 (even though the actual interception of the cruise missile can’t be seen.)

Generally speaking, combat aircraft can intercept cruise missiles and engage them. However, such missiles are quite difficult to detect: they are optimised for low level flying through the Terrain Following capability, have a low radar cross-section and heat signature and, they are small.

This means that an inteceptor using a long-range missile from the right position and altitude might be able to do the job. But it shouldn’t be something too easy.

Testing conducted by the U.S. Navy has shown that shooting down cruise missiles, flying at low-level and high-speed is actually a pretty difficult task: on Sept. 12, 2016, a live test fire demonstration involved the integration of U.S. Marine Corps F-35B from the Marine Operational Test and Evaluation Squadron (VMX 1), based in Edwards Air Force Base, with existing Naval Integrated Fire Control-Counter Air (NIFC-CA) architecture.

F-35 and Aegis Combat System Successfully Demonstrated Integration Potential in First Live Missile Test (Lockheed Martin)

The F-35B acted as an elevated sensor (to detect an over-the-horizon threat as envisaged for the F-22) that sent data through its Multi-Function Advanced Data Link to a ground station connected to USS Desert Ship (LLS-1), a land-based launch facility designed to simulate a ship at sea. Using the latest Aegis Weapon System Baseline 9.C1 and a Standard Missile 6, the system successfully detected and engaged the target: a test that proved how detecting, tracking and engaging cruise missiles requires cutting edge anti-surface and anti-air weapons.

On the other side it is somehow interesting to note that a rather old weapons system, the MiG-31, albeit operating a Passive Electronically Scanned Array (PESA) radar, can be able to intercept stealthy cruise missiles (like the Kh-101 reportedly used in some tests), with the support of an AWACS plane.

We don’t actually know the exact type of test the Russians conducted. For sure it wasn’t a low flying cruise missile like a Tomahawk, since this was reportedly flying in the “near space.”

The video below shows a past test when four MiG-31s, supported by an A-50 Mainstay, reportedly fired and hit a Kh-55 launched by a Tu-95 Bear.

“The cruise missile was destroyed at an altitude of 300 meters above the ground from a distance of 10 kilometers (6.2 miles) from the target,” the Russian MoD said in a statement, quoted by Russian-owned outlet Sputnik News, back in 2015.

Anyway, Russia has other weapons systems nominally capable of repelling cruise missile attacks, as well as jets and drones: the S-400 anti-aircraft defense is able to engage all types of aerial targets including aircraft (someone says even VLO – Very Low Observable ones), drones and ballistic and cruise missiles within the range of 250 miles at an altitude of nearly 19 miles.

Let us know what you think and know about the MiG-31 ability to intercept waves of cruise missiles.

Top image: file artwork by Pravda.ru
