UK F-35B Performs World’s First Shipborne Rolling Vertical Landing During HMS Queen Elizabeth Trials

The F-35 Patuxent River Integrated Test Force (ITF) achieved a new milestone performing a Shipborne Rolling Vertical Landing (SRVL) on aircraft carrier HMS Queen Elizabeth.

On Oct. 13, an F-35B STOVL (Short Take Off Vertical Landing) variant of the Joint Strike Fighter performed the first  Shipborne Rolling Vertical Landing (SRVL) on the flight deck of HMS Queen Elizabeth, as part of the ongoing First of Class Flight Trials (Fixed Wing), or FOCFT (FW). BAE Systems test pilot Pete “wizzer” Wilson, achieved the F-35B’s first real SRVL touching down at about 40 knots and decelerating to a standstill in about 175 feet.

Britain’s newest aircraft carrier (able to accommodate up to 24 F-35Bs out of the planned 138 F-35 Lightning jets) and the F-35 Patuxent River Integrated Test Force (ITF) are conducting a variety of flight maneuvers and deck operations to develop the F-35B operating envelope for QEC carriers.

A composite image of the first SRVL.

Among the most important parts of the trials are the rolling vertical landings: as the acronym suggests, STOVL aircraft use the vertical landing to return to the ship. Using this kind of procedure, the approaching aircraft slowly reaches a hovering position to the port side of the ship before moving sideways over the deck and descending slowly. This technique has pretty strict weight requirements because of the thrust required to keep the aircraft airborne the time needed to put the wheels down. The rolling technique is intended to allow pilots to recover to the ship with more stores: the combination of thrust from its rotating nozzle, lift-fan and lift generated by the wing as an effect of the (slow) forward movement of the aircraft can save up to 7000lbs greater all up weight (UAW). Without the SRVL technique, the F-35B would be forced to jettison some or all of its external store when returning to the ship.

According to some sources the Soviet Yak-38 “Forger” jets could perform rolling landings on carrier decks but required the use of a safety barrier net; however, it’s not clear whether actual tests were conducted at sea.



In order to prepare to the first SRVL pilots and engineers tested the new technique using BAE Systems’ F-35/QEC Integration Simulator—a full motion, dome simulator—based in Warton, England. Some 3,000 takeoffs and landings were important to discover “where the edges of the test envelope are,” said Royal Air Force Sq. Ldr. Andy Edgell, FOCFT (FW) lead test pilot at the Pax River ITF.

“SRVL tests are truly experimental,” Edgell said. “It involves landing a fast jet onto an aircraft carrier with forward relative speed but without the braking assistance typically provided by an arresting gear and hook. It’s going to be a really rewarding moment for British aviation to watch that procedure actually take place.”

Back in 2007, Qinetiq’s VAAC Harrier testbed was used by the Aircraft Test and Evaluation Centre using a “dummy deck” at Qinetiq’s Boscombe Down site in Wiltshire, to assess the possibility to perform SRVL approaches as a way to use thrust-vectoring to a slow speed while still gaining the benefit of wing-borne lift.

The UK is the only nation currently planning to use the SRVL technique. However, the US Marine Corps and the Italian Navy (which should operate the F-35B to replace the AV-8B+ Harrier II from Italy’s Cavour aircraft carrier in the future) might take advantage of the rolling landing in the future, leveraging the testing conducted by the F-35 ITF aboard HMS Queen Elizabeth.

Following the crash occurred on Sept. 28 and involving a U.S. Marine Corps F-35B, the U.S. Services and international partners temporarily suspended F-35 flight operations while conducting a fleet-wide inspection of a fuel tube within the engine on all F-35 aircraft. British F-35Bs involved in the flight trials from HMS Queen Elizabeth and Italian F-35 were not grounded though, as inspections did not find the faulty part.

Top image credit: Royal Navy / Crown Copyright

Observing The British F-35B Lightning At Work At RAF Marham

Spotting outside RAF Marham, home of the UK’s stealth aircraft, on an ordinary day.

On Tuesday Sept. 25 afternoon, The Aviationist’s contributor Alessandro Fucito went to RAF Marham, near the village of Marham in the English county of Norfolk, East Anglia, UK, to take some photographs of the first British F-35B STOVL (Short Take Off Vertical Landing) stealth jets based there.

Whilst test pilots at the F-35 Integrated Test Force at NAS Patuxent River, Md. are involved in the first of two First of Class Flight Trials (Fixed Wing) phases, performing a variety of flight maneuvers and deck operations on board HMS Queen Elizabeth to develop the F-35B operating envelope for Britain’s newest aircraft carriers, the 617 Sqn at RAF Marham has eventually ramped up flying activity to achieve initial operating capability (IOC) from land bases. Indeed, there is still a lot to do, considered that the UK-based F-35Bs have flown less than expected during the summer: as reported by Aviation Week’s Tony Osborne recently, none of the UK-based aircraft has flown for 34 consecutive days, from Jul. 26 to Aug. 29 (not including the arrival of five F-35Bs belonging to the second batch which arrived from the U.S. on Aug. 3)!

Side view for the F-35B ZM147 performing pattern work at RAF Marham on Sept. 25. (All images: Alessandro Fucito).

According to Osborne, little flying preceded the “mysterious month-long flying break”, considered that just 21 or 22 flights were flown up to July 26 (mainly local training sorties as well as the first vertical landings), including sorties flown in support of air show display flyovers. “The UK defense ministry insists the break in flying is a result of extensive maintenance checks and personnel on leave. But when the first batch of aircraft arrived in June, crews said they were expecting an intensive flying regime to achieve IOC,” commented Osborne.

Conventional approach to RWY19.

That said, our contributor Fucito has counted two F-35 sorties (and three Tornado ones) even though the Lightning jet was the same, ZM147, flying both missions. During each flight, the pilot has practiced three approaches, both in conventional and STOVL configuration, to the runway in use (RWY 01/19, the one that is used for short takeoffs and vertical landings, the other one, the 06/24 was closed for works). For those interested, the aircraft sported the type’s three Luneburg lenses (radar reflectors).

F-35B ZM147 configured for a Vertical Landing.

Although the activity was far from being “intense” at least the two F-35 sorties provided an opportunity for some interesting shots that you can find in this post.

The F-35B flew two sorties on Sept. 25: each included three approaches, both conventional and in Vertical Landing configuration.

As a side note, although they have not been grounded after a U.S. Marine Corps F-35B has crashed in the US, someone has noticed that there was no Lightning activity at RAF Marham this week.

Here Are Some Photographs of the F-35B Lightning Jets Landing on (and Launching From) Britain’s Newest Carrier for the First Time

Royal Navy Commander Nathan Gray and RAF Squadron Leader Andy Edgell were the first pilots to land their F-35 Lightning stealth jets on the flight deck of HMS Queen Elizabeth.

In the last 24 hours we have commented two quite different F-35B Lightning II-related news: the first air strike in Afghanistan and the first crash in South Carolina. Both events involved U.S. Marine Corps STOVL (Short Take Off Vertical Landing) variant aircraft. However, these were not the only newsworthy events: on Tuesday Sept. 25, 2018, Royal Navy Cmdr. Nathan Gray and Royal Air Force Sq. Ldr. Andy Edgell, both test pilots at the F-35 Integrated Test Force at NAS Patuxent River, Md., were the first pilots to land the stealth F-35B on board HMS Queen Elizabeth.

The first landings and subsequent take-offs from HMS Queen Elizabeth “are the culmination of a British endeavor lasting more than a decade to bring an aircraft carrier back to the UK’s arsenal,” says an official U.S. DoD release.

Two F-35B Lightning II fighter jets successfully landed onboard HMS Queen Elizabeth for the first time this week, laying the foundations for the next 50 years of fixed wing aviation in support of the UK’s Carrier Strike Capability.
Royal Navy Cmdr. Nathan Gray made history by being the first to land on, followed by Royal Air Force Sq. Ldr. Andy Edgell, both test pilots at the Integrated Test Force (ITF) based at Naval Air Station Patuxent River, Maryland.
Photo courtesy of Lockheed Martin

The landings on Britain’s newest aircraft carrier (able to accommodate up to 24 F-35Bs out of the planned 138 F-35 Lightning jets) kicked off the first of two First of Class Flight Trials (Fixed Wing) phases, held back-to-back this fall, where the ITF team plans to perform a variety of flight maneuvers and deck operations to develop the F-35B operating envelope for QEC carriers. According to the ITF, the tests “will evaluate jet performance on over 200 test points during different weather and sea conditions as well as the aircraft’s integration with the ship. A third FOCFT (FW) phase followed by operational testing is scheduled for 2019.”

Two F-35B Lightning II fighter jets successfully landed onboard HMS Queen Elizabeth for the first time this week, laying the foundations for the next 50 years of fixed wing aviation in support of the UK’s Carrier Strike Capability. Shortly afterwards, once a deck inspection has been conducted and the all-clear given, Royal Navy Cmdr. Nathan Gray, F-35 Integrated Test Force at NAS Patuxent River, Md., became the first pilot to take off using the ship’s ski-ramp.
Courtesy photo by Royal Navy

The first landings were performed as HMS Queen Elizabeth operated off the U.S. East Coast. The aircraft carrier left Portsmouth in August, crossing the Atlantic to conduct the flying trials and joint training with the US Navy. The flight trials are scheduled to take around 11 weeks and +500 take-off and landings. The target is to be ready for a deployment from 2021.

F-35B prepares to land. (LM)

In an official Royal Navy release, the Commanding Officer of HMS Queen Elizabeth, Captain Jerry Kyd, said: “I am quite emotional to be here in HMS Queen Elizabeth seeing the return of fixed-wing aviation, having been the captain of the aircraft carrier which launched the last Harrier at sea nearly eight years ago.

“The regeneration of big deck carriers able to operate globally, as we are proving here on this deployment, is a major step forward for the United Kingdom’s defence and our ability to match the increasing pace of our adversaries. The first touch-downs of these impressive stealth jets shows how the United Kingdom will continue to be world leaders at sea for generations to come.”

Two F-35B Lightning II fighter jets successfully landed onboard HMS Queen Elizabeth for the first time this week, laying the foundations for the next 50 years of fixed wing aviation in support of the UK’s Carrier Strike Capability.
Royal Navy Cmdr. Nathan Gray made history by being the first to land on, followed by Royal Air Force Sq. Ldr. Andy Edgell, both test pilots at the Integrated Test Force (ITF) based at Naval Air Station Patuxent River, Maryland.
Photo courtesy of Lockheed Martin

Commodore Andrew Betton, the commander of the UK’s Carrier Strike Group, said: “The Queen Elizabeth-class carriers have been specifically designed and built to operate the F-35, offering an immensely flexible and potent combination to deliver military effect around the world.

F-35B on the ski jump. (LM)

“Conducting these trials is a critical and exciting step on this journey and I applaud the many thousands of civilian and military personnel who have played a part in bringing the strategic ambition to reality.”

Royal Navy Cmdr. Nathan Gray in his F35B following the first deck landing aboard HMS Queen Elizabeth. Gray and Royal Air Force Sq. Ldr. Andy Edgell, both test pilots at the F-35 Integrated Test Force at Naval Air Station Patuxent River, Md, landed the first two jets on the new British aircraft carrier this week.
Courtesy photo by Royal Navy





UK’s First Four F-35B Jets Currently On Their Way To The UK and Their New Home Of RAF Marham

The first F-35B aircraft are expected to land later today to join the RAF 617 Squadron “Dambusters”.

Earlier today four Lightning jets of 617 Squadron took of from Marine Corps Air Station Beaufort, South Carolina, where the famous “Dambusters” unit was reactivated on Apr. 17, 2018, to undertake the transatlantic crossing and arrive at RAF Marham, the new home of the UK’s Lightning Force.

The F-35Bs are being supported by three RAF Voyagers tankers: ZZ330 (RRR9101, radio callsign “Ascot 9101”), ZZ335 (RRR9102, “Ascot 9102”) and ZZ331 (RRR9103 “Ascot 9103”). ZZ330 departed Charleston and picked up the four  F-35Bs from MCAS Beaufort. That took the Lightning as far as ZZ331 and ZZ335 out from Gander that are towing the F-35 across the Atlantic. Supporting the transatlantic trip is also an A400M ZM401 (RRR4085).

The four jets are due to land at RAF Marham this evening, one day later than expected: their mission was delayed 24 hours by the bad weather along the planned route.

The Royal Air Force has also shared a video on social media showing one of the Lightnings during aerial refueling:

According to Air Forces Monthly, nine of the 11 UK F-35Bs currently on strength at MCAS Beaufort (where the British squadron operates under Marine Fighter Attack Training Squadron 501) are expected to arrive in the UK for the RAF’s centenary celebrations this summer, including a flypast over London. And, above all, later this year, the UK F-35Bs will deploy aboard the Royal Navy aircraft carrier HMS Queen Elizabeth for the first time.

“Lightning II has been designed from the outset to carry out a wide range of mission types, able to use its very low observable characteristics to penetrate Integrated Air Defence Systems and strike a number of types of targets. In a permissive environment, Lightning II is able to carry weapons on external pylons, as well as in the internal weapon bays. This will allow a maximum weapon payload of 6 Paveway IV, 2 AIM-120C AMRAAM, 2 AIM-132 ASRAAM (Advanced Short-Range Air-to-Air Missile) and a missionised 25mm gun pod,” says official RAF documentation.

“In 2019 we will also start our integration work for the new Meteor [beyond-visual-range air-to-air missile, BVRAAM] and SPEAR Cap 3 [Selective Precision Effects At Range Capability 3] weapon in order to deliver a phase one capability for those assets in 2021,” Martin Peters, BAE Systems’ F-35 flight test manager and test lead for STOVL (short take-off and landing), told AFM.

Top image credit: Crown Copyright

Sea Vixen Future In Question Following Analysis of Belly Landing Damage

Inspectors Suggest Restoration After Belly Landing Will Be Extensive.

The Royal Navy Heritage website Navy Wings has announced the status of repairs and prospects for restoration of their De Havilland DH.110 Sea Vixen, XP924 G-CVIX “Foxy Lady” following its emergency wheels-up landing at Yeovilton, UK, on May 27.

As reported by The Aviationist with both video and photos by photographer Scott Dabinett, “Foxy Lady” sustained damage during the emergency landing. An analysis of the damage to components and airframe reveal that, unfortunately, “Foxy Lady” is unlikely to be in the air any time soon.

Emergency crews respond to the Sea Vixen belly-landing. (Photo: BBC)

On Jul. 25 Navy Wings editors wrote, “We have now suspended the aircraft from maintenance procedures while we continue to investigate plans for complete restoration.”

That the routine flying maintenance routine has been suspended is bad news as it suggests there is no capability to get the Sea Vixen airworthy during the remainder of the airshow season. However, the statement about investigating plans for complete restoration is hopeful.

Key to the restoration and return to flight operations of the Sea Vixen is some reorganization of roles for key personnel within the Royal Navy Heritage organization. Chief Engineer Brian Johnstone, who was originally intending to retire from his role at Royal Navy Heritage, will remain with the project as a consultant. He will advise the new Chief Engineer, Mr. Kevin Bugg, in his new role as Chief Engineer of the Sea Vixen.

Meanwhile, Sea Vixen demonstration pilot Cdr. Simon Hargreaves OBE, Royal Navy Reserves, has been awarded the “Green Endorsement” commendation for his role in the controlled belly landing in the Sea Vixen on May 27. Hargreaves airmanship certainly minimized damage to the aircraft as it landed without landing gear. Fleet Air Arm, Rear Admiral Keith Blount OBE, cited Hargreaves for exceptional skill in the incident.

Demo pilot Cdr. Simon Hargreaves, OBE, awarded the Green Endorsement award for airmanship in his emergency landing of the Sea Vixen. (Photo: Navy Wings)

Navy Wings is an organization that helps maintain up to fourteen different historic aircraft through their sub-organizations. In addition to the Sea Vixen they include a Supermarine Spitfire Mk. XV currently undergoing restoration and slated to fly in 2018 along with two Sea Fury aircraft, one undergoing ground testing and one in restoration.

Top image credit: Navy Wings
