Some recent photos of the Hill AFB F-35s deployed to Kadena Okinawa, seem to suggest the 5th Generation fighters have started operating in “stealth mode”.
Stealth aircraft, such as the F-22 Raptor or the F-35 Lightning II 5th generation jets are equipped with Luneburg (or Luneberg) lenses: radar reflectors used to make the LO (Low Observable) aircraft (consciously) visible to radars. These devices are installed on the aircraft on the ground are used whenever the aircraft don’t need to evade the radars: during ferry flights when the aircraft use also the transponder in a cooperative way with the ATC (Air Traffic Control) agencies; during training or operative missions that do not require stealthiness; or, more importantly, when the aircraft operate close to the enemy whose ground or flying radars, intelligence gathering sensors.
In fact, tactical fighter-sized stealth aircraft are built to defeat radar operating at specific frequencies; usually high-frequency bands as C, X, Ku and S band where the radar accuracy is higher (in fact, the higher the frequency, the better is the accuracy of the radar system).
However, once the frequency wavelength exceeds a certain threshold and causes a resonant effect, LO aircraft become increasingly detectable. For instance, ATC radars, that operate at lower-frequency bands are theoretically able to detect a tactical fighter-sized stealth plane whose shape features parts that can cause resonance. Radars that operate at bands below 300 MHz (lower UHF, VHF and HF radars), such as the so-called Over The Horizon (OTH) radars, are believed to be particularly dangerous for stealth planes: although they are not much accurate (because lower frequency implies very large antenna and lower angle accuracy and angle resolution) they can spot stealth planes and be used to guide fighters equipped with IRST towards the direction the LO planes might be.
F-35s deployed abroad usually feature their typical four radar reflectors: to exaggerate their real RCS (Radar Cross Section) and negate the enemy the ability to collect any detail about their LO “signature”. As happened during the short mission to Estonia and then Bulgaria, carried out by the USAF F-35As involved in the type’s first overseas training deployment to Europe or when, on Aug. 30, 2017, four U.S. Marine Corps F-35B Lightning II joined two USAF B-1B Lancers for the JSF’s first show of force against North Korea: the F-35Bs flew with the radar reflectors, a sign they didn’t want their actual radar signature to be exposed to any intelligence gathering sensor in the area.
The two radar reflectors on the right side of the F-35A (the remaining two are located in the same positions on the left side). Image credit: LM (hightlight by Author)
Since they almost always fly with the radar reflectors, photographs of the aircraft without the four notches (two on the upper side and two on the lower side of the fuselage) are particularly interesting: for instance, some shots taken on Jan. 24, 2018 and just released by the U.S. Air Force show F-35As deployed to Kadena AB, Japan, in October as a part of the U.S. Pacific Command’s Theater Security Package program, preparing to launch without their Luneberg reflectors.
The lack of reflector on the top left position of this F-35 is pretty evident in the following photographs:
A U.S. Air Force F-35A Lightning II from Hill Air Force Base, Utah, goes through pre-flight checks prior to taxiing Jan. 25, 2018, at Kadena Air Base, Japan. The F-35A is a 5th-generation stealth fighter developed to safely penetrate areas while avoiding radar detection. (U.S. Air Force photo by Senior Airman Quay Drawdy)
U.S. Air Force Senior Airman Jacob Valdez, 34th Aircraft Maintenance unit crew chief, performs pre-flight checks prior to a training flight Jan. 25, 2018, at Kadena Air Base, Japan. The F-35A is a 5th-generation stealth fighter developed to safely penetrate areas while avoiding radar detection. (U.S. Air Force photo by Senior Airman Quay Drawdy)
U.S. Air Force Senior Airman Jacob Valdez, 34th Aircraft Maintenance unit crew chief, communicates with Maj. Matthew Olson, F-35A Lightning II pilot from Hill Air Force Base, Utah, before a training flight Jan. 25, 2018, at Kadena Air Base, Japan. The F-35A is deployed under U.S. Pacific Command’s theater security package program, which has been in operation since 2004. (U.S. Air Force photo by Senior Airman Quay Drawdy)
For comparison, the following photo shows one of the 388FW F-35A jets on the ground at Kadena in November 2017 with the radar reflector.
U.S. Air Force Staff Sgt. Patrick Charles, 34th Aircraft Maintenance Unit crew chief, goes through pre-flight procedures Nov. 16, 2017, at Kadena Air Base, Japan. Rotational forces are integral to increasing our military combat capabilities, which are essential to U.S. power projection and security obligations. (U.S. Air Force photo by Airman 1st Class Greg Erwin)
Obviously the lack of radar reflectors is not a big deal: during their deployment to RAF Lakenheath last year, F-35As of the 388th FW have flown without reflectors some local sorties with the 48th FW F-15E Strike Eagles (for example on Apr. 26, 2017). However, photographs of deployed F-35s without Luneburg Lenses are pretty rare and, for this reason, interesting and newsworthy.
As North Korean Tensions Moderate Ahead of Olympics, A New Threat Emerges: Accidental Engagement.
“I started running for shelter” one man told U.S. network CNN about his response to the false nuclear threat warning text sent to Hawaii residents on Saturday, Jan. 13, 2018. The automated alert system was accidentally actuated by a routine drill at shift change that went wrong. During the alert, that included the message “This is not a drill”, hotel guests were evacuated into basement shelters, some people abandoned vehicles on the road and videos were posted of a man trying to open a manhole cover to seek shelter. According to a report in GlobalSecurity.org, U.S. Homeland Security Chief Kirstjen Nielsen made a statement the next day that it was “unfortunate” there was a false emergency alarm about an incoming missile in Hawaii, but said authorities are “all working to make sure it doesn’t happen again.”
It took 38 minutes for Hawaii’s Emergency Management Agency to issue a statement saying the alert was an error. But even when the alert error message was delivered, tensions remained high on the island state. The Hawaiian island of Oahu was the scene of the Japanese attack on Pearl Harbor at the beginning of U.S. involvement in WWII on Dec. 7, 1941, and while few current residents of the island who survived that attack 77 years ago are still alive, the legacy of the Pearl Harbor attack permanently looms in the background of escalating tensions in the Pacific region with North Korea today.
The incident comes as relations between the South Korea and North Korea show possible signs of moderation ahead of the winter Olympics that begin on Feb. 9, 2018 in PyeongChang County, South Korea. North Korean and U.S. tensions remain high, but have not worsened in recent weeks. Some observers maintain that any evolution other than a worsening of relations between the U.S. and North Korea suggests improvement as Washington and Pyongyang continue their sabre rattling war of words.
But the risk of accidental engagement between the U.S and North Korea remains high, and these risks are titanic.
While the incident in Hawaii was a local level erroneous alert only, it typifies exposure to accidents that are inherent in any system where human involvement could introduce error. In the current political and strategic environment, the risk of accidental engagement represents the most tangible threat to any possible peace process in the region. Japan, North Korea, the U.S. and South Korea remain on a tenuous brink in the Sea of Japan and the Yellow Sea. This stand-off could easily escalate to a significant armed exchange entirely by error.
As with many strategic and defense realities, the late fiction author Tom Clancy was prescient of this risk. Clancy wrote this passage about a heated meeting between fictional characters, National Security Advisor Dr. Jeffrey Pelt and Soviet Ambassador to the U.S. Andrei Lysenko, in “The Hunt for Red October”:
“It would be well for your government to consider that having your ships and ours, your aircraft and ours, in such proximity… Is inherently DANGEROUS. Wars have begun that way, Mr. Ambassador.”
The risk of accidental near-nuclear attack has been consistent in fiction, but rare in reality. But it has happened.
On Sept. 26, 1983, an accidental alert in the Soviet Union indicated that the U.S. had launched a missile at the USSR. Then it got worse. The system reported a follow-on salvo of five U.S. ICBMs inbound toward the Soviet Union. To Soviet crews manning the early warning systems in the Oko satellite based Nuclear Attack Warning Center it seemed like a text-book U.S. first strike. U.S. rhetoric at the time spoke of “maintaining our first strike capability”, making the warning all the more urgent. The incident came only three weeks after the Soviets accidentally shot down a civilian Boeing 747 airliner, Korean Airlines flight 007, killing everyone on board. The aircraft had strayed into prohibited Soviet airspace and was mistaken for a U.S. spy plane. Real-life Soviet Lieutenant Colonel Stanislav Yevgrafovich Petrov was on duty at the time, monitoring the incoming intelligence. Based on his analysis of the data Lt. Col. Petrov judged the alarms to be an error. He later said they did not exactly match the U.S. nuclear attack doctrine, so he did not elevate the alert. Lt. Col. Petrov’s human intervention was the first circuit breaker between accident and global calamity. He received neither reprimand nor award. Petrov died anonymously in May, 2017.
As with both real and fictional accidental engagements or near-engagements the common circumstances are large numbers of military assets from adversary nations in close proximity to one another combined with a protracted phase of elevated alert status. The stress of long periods at high alert levels combined with complex procedures for differentiating friend or foe are often set against a backdrop of dynamic rules of engagement. Accidents happen.
In November 2017, the U.S. Navy released reports on two serious accidents where Navy ships collided with other vessels in close proximity. On June 17, 2017 the Arleigh-Burke class destroyer USS Fitzgerald (DDG-62) was struck by the commercial container ship ACX Crystal in the narrow commercial shipping approach to Tokyo Bay. Seven members of the Fitzgerald’s crew died in the accident and her commanding officer was injured. In another incident only two months later the Arleigh-Burke class destroyer, the USS John McCain (DDG-56), was hit by the Liberian flag vessel Alnic MC in the crowded shipping approaches to the Singapore Strait. Ten crewmembers of the USS John McCain died in the accident.
Collisions with U.S. Navy vessels at sea could spark an accidental engagement. (Photo: US Navy)
Even more foreboding is the July 3, 1988 incident in the Persian Gulf when the U.S. Navy Ticonderoga Class guided missile cruiser USS Vincennes (CG-49) accidentally shot down civilian passenger flight Iran Air flight 655, an Airbus A300-B2 airliner. All passengers and crew on board were killed. The crew of the USS Vincennes had incorrectly determined that the civilian airliner was an Iranian F-14 Tomcat that was attacking them. An investigation revealed the crew of the USS Vincennes attempted to contact Iran Air Flight 655 ten times before engaging it with two SM-2MR surface-to-air missiles, one of which hit the airliner and destroyed it. Some reports suggested the incident stemmed from psychological pressure the crew was under as a result of high alert status caused by other incidents in the region (one year before this incident, in May 1987, the guided missile frigate USS Stark had been attacked by an Iraqi Mirage F-1 jet and 37 American sailors had perished during the clash).
It is a short leap to imagine an incident that would be much more serious than this last year’s accidental collisions with merchant vessels or the recent erroneous warning messages being sent. There are currently three U.S. Navy carrier battle groups in the region. The USS Ronald Reagan (CVN-76), the USS Nimitz (CVN-68) and the USS Theodore Roosevelt (CVN-71) are all operational in the area around North Korea. Each vessel also has a significant support armada. Japanese and South Korean military vessels are also active in the region making for a very crowded patrol space.
The key to avoiding accidental engagements on each side will be adherence to rules of engagement and constant vigilance with navigation and communication. These are all standard protocols for all parties involved but fatigue and fear can degrade procedure in the real world. But perhaps the last circuit breaker between a tense stand-off and a rapidly escalating armed exchange are the responsible individuals with cool heads and an understanding of the true terror of war, accidental or not. We rely on them to maintain this tenuous peace.
One of the few EC-130H Compass Call aircraft, capable to find and hit the enemy forces with denial of service (and possibly cyber) attacks on their communication networks, has been deployed to Osan Air Base, South Korea.
The EC-130H Compass Call is a modified Hercules tasked with various types of signals surveillance, interdiction and disruption. According to the U.S. Air Force official fact sheets: “The Compass Call system employs offensive counter-information and electronic attack (or EA) capabilities in support of U.S. and Coalition tactical air, surface, and special operations forces.”
The USAF EC-130H overall force is quite small, consisting of only 14 aircraft, based at Davis-Monthan AFB (DMAFB), in Tucson, Arizona and belonging to the 55th Electronic Combat Group (ECG) and its two squadrons: the 41st and 43rd Electronic Combat Squadrons (ECS). Also based at DMAFB and serving as the type training unit is the 42nd ECS that operates a lone TC-130H trainer along with some available EC-130Hs made available by the other front-line squadrons.
An EC-130H Compass Call travels along the taxiway at an undisclosed location in Southwest Asia, June 27, 2017. Compass Call is an airborne tactical weapon system that uses noise jamming to disrupt enemy command and control communications and deny time-critical adversary coordination essential for enemy force management. (U.S. Air Force photo by Tech. Sgt. Jonathan Hehnly)
The role of the Compass Call is to disrupt the enemy’s ability to command and control their forces by finding, prioritizing and targeting the enemy communications. This means that the aircraft is able to detect the signals emitted by the enemy’s communication and control gear and jam them so that the communication is denied. The original mission of the EC-130H was SEAD (Suppression of Enemy Air Defenses): the Compass Call were to jam the enemy’s IADS (Integrated Air Defense Systems) and to prevent interceptors from talking with the radar controllers on the ground (or aboard an Airborne Early Warning aircraft). Throughout the years, the role has evolved, making the aircraft a platform capable of targeting also the signals between UAVs (Unmanned Aerial Vehicles) and their control stations.
According to the official data:
The EC-130H fleet is composed of a mix of Baseline 1 and 2 aircraft. The 55th ECG recently eclipsed 10,900 combat sorties and 66,500 flight hours as they provided U.S. and Coalition forces and Joint Commanders a flexible advantage across the spectrum of conflict. COMPASS CALL’s adaptability is directly attributed to its spiral upgrade acquisition strategy guided by the Big Safari Program office and Air Force Material Command’s 661st Aeronautical Systems Squadron based in Waco, Texas. Combined efforts between these agencies ensure the EC-130H can counter new, emergent communication technology.
The Block 35 Baseline 1 EC-130H provides the Air Force with additional capabilities to jam communication, Early Warning/Acquisition radar and navigation systems through higher effective radiated power, extended frequency range and insertion of digital signal processing versus earlier EC-130Hs. Baseline 1 aircraft have the flexibility to keep pace with adversary use of emerging technology. It is highly reconfigurable and permits incorporation of clip-ins with less crew impact. It promotes enhanced crew proficiency, maintenance and sustainment with a common fleet configuration, new operator interface, increased reliability and better fault detection.
Baseline 2 has a number of upgrades to ease operator workload and improve effectiveness. Clip-in capabilities are now integrated into the operating system and, utilizing automated resource management, are able to be employed seamlessly with legacy capabilities. Improved external communications allow Compass Call crews to maintain situational awareness and connectivity in dynamic operational and tactical environments.
Delivery of Baseline-2 provides the DoD with the equivalent of a “fifth generation electronic attack capability.” A majority of the improvements found in the EC-130H Compass Call Baseline-2 are classified modifications to the mission system that enhance precision and increase attack capacity. Additionally, the system was re-designed to expand the “plug-and-play” quick reaction capability aspect, which has historically allowed the program to counter unique “one-off” high profile threats. Aircraft communication capabilities are improved with expansion of satellite communications connectivity compatible with emerging DoD architectures, increased multi-asset coordination nets and upgraded data-link terminals. Furthermore, modifications to the airframe in Baseline-2 provide improved aircraft performance and survivability.
Although it’s not clear whether this ability has already been translated into an operational capability, in 2015, a USAF EC-130H Compass Call aircraft has also been involved in demos where it attacked networks from the air: a kind of in-flight hacking capability that could be particularly useful to conduct cyberwarfare missions where the Electronic Attack aircraft injects malware by air-gapping closed networks.
With about one-third of the fleet operating in support of Operation Inherent Resolve (indeed, four EC-130Hs, teaming up with the RC-135 Rivet Joint and other EA assets, are operating over Iraq and Syria to deny the Islamic State the ability to communicate), the fact that a single EC-130H (73-1590 “Axis 43”) was recently deployed from Davis Monthan AFB to Osan Air Base, South Korea, where it arrived via Yokota, on Jan. 4, 2018, it’s pretty intriguing.
Airborne from Yokota AB, Japan routing to Osan AB, South Korea
Update: some of our sources have suggested that the aircraft was deployed to perform anti-IED (Improvised Electronic Device) tasks during the Winter Olympics, kicking off on Feb. 9, 2018 in PyeongChang County, South Korea.
The U.S. Air Force has just deployed three B-2 Spirits stealth bombers to Guam.
Three B-2 Spirit strategic stealth bombers along with approximately 200 Airmen belonging to the 509th Bomb Wing, Whiteman Air Force Base, were deployed to Andersen Air Force Base, in support of U.S. Pacific Command’s (PACOM) Bomber Assurance and Deterrence mission.
The stealth bombers, are due to be involved in what the U.S. Pacific Command defined a “short-term deployment” during which they will conduct “local and regional training sorties, and will integrate capabilities with key regional partners, ensuring bomber crews maintain a high state of readiness and crew proficiency.”
A B-2 Spirit, assigned to the 509th Bomb Wing, Whiteman Air Force Base, taxis on the flightline Jan. 8, 2018, at Andersen Air Force Base, Guam. Approximately 200 Airmen and three B-2 Spirits from Whiteman Air Force Base (AFB), Missouri, deployed to Andersen AFB in support of U.S. Pacific Command’s (PACOM) Bomber Assurance and Deterrence mission. U.S. Strategic Command bombers regularly rotate through the Indo-Pacific region to conduct U.S. PACOM-led air operations, providing leaders with deterrent options to maintain regional stability. During this short-term deployment, the B-2s will conduct local and regional training sorties and will integrate capabilities with key regional partners, ensuring bomber crews maintain a high state of readiness and crew proficiency (Air Force photo by Staff Sgt. Joshua Smoot) .
Interestingly, the B-2s have joined the “several” B-1B Lancers deployed to Guam to support the U.S. Pacific Command’s (USPACOM) Continuous Bomber Presence mission. The Bones (using the nickname popular among their aircrews) have been involved in several shows of force around the Indo-Asia-Pacific region, but they can’t carry any kind of nuclear weapon. So, the B-2 deployment in the region brings a nuclear bomber capability closer to North Korea.
Still, it must be noticed that the U.S. Strategic Command bombers regularly rotate through the region to conduct U.S. PACOM-led air operations, providing leaders with deterrent options to maintain regional stability. The B-2s periodically perform round-trip missions from their homebase in Missouri, from where they have already proved to be able to hit targets located anywhere across the world. The last time the B-2s deployed to Guam was in August 2016 when the 509th BW conducted another short-term deployment: exploiting the presence of both the B-52 Stratofortress, B-1B Lancer and B-2 Spirit, on Aug. 17, 2016, the U.S. Air Force was able to launch the bomber trio in an unprecedented coordinated operation in the U.S Pacific Command AOR (Area Of Operations). The three aircraft launched in sequence from Andersen Air Force Base, Guam, performed a flyover and then dispersed to conduct simultaneous operations in the South China Sea and Northeast Asia.
Two of the three B-2s that are currently in Guam departed on Jan. 7, 2017 and arrived at Andersen Air Force Base on Jan. 8 using radio callsigns MYTEE 21, MYTEE 22. What would’ve been MYTEE23 went tech so it arrived on Jan. 9 alone.
The USMC may have their “baptism of fire” with the F-35B next year.
The F-35B, the STOVL (Short Take Off Vertical Landing) variant of the Lightning II 5th generation aircraft is expected to deploy to the Pacific and Central Command theaters in 2018, the Marine Corps Times reported.
According to Jeff Schogol, the F-35B, that can operate from amphibious assault ships, “is expected to deploy with two Marine expeditionary units to the Pacific and Central Command theaters in the spring and summer. […] The first deployment will be with the 31st MEU aboard the amphibious assault ship USS Wasp and the second will be with the 13th MEU aboard the amphibious assault ship USS Essex, said spokeswoman Capt. Sarah Burns.”
The first deployment to the U.S. Central Command AOR (area of responsibility) – that includes Iraq, Syria, Iran, Yemen and Afghanistan – has long been anticipated. In 2016, Lt. Gen. Robert Walsh, head of Marine Corps Combat Development Command, told reporters that the service was planning to deploy the F-35B to the CENTCOM area of operations aboard the USS Essex (six more F-35Bs were to deploy to the Pacific aboard the USS Wasp).
The 2018 deployment follows the relocation of Marine Fighter Attack Squadron 121 (VMFA-121), an F-35B squadron with 3rd Marine Aircraft Wing to MCAS Iwakuni, Japan, from MCAS (Marine Corps Air Station) Yuma, Arizona, on Jan. 9, 2017. Since then, the F-35B have started operating in the region, taking part in local drills as well as some routine “shows of force” near the Korean Peninsula: for instance, on Aug. 30, four U.S. Marine Corps F-35B Lightning II joined two USAF B-1B Lancers from Guam onf a 10-hour mission that brought the “package” over waters near Kyushu, Japan, then across the Korean Peninsula. Interestingly, during that mission, the F-35Bs flew with the radar reflectors used to make LO (Low Observable) aircraft clearly visible on radars and also dropped their 1,000-lb GBU-32 JDAMs (Joint Direct Attack Munitions) on Pilsung firing range. On a subsequent mission on Sept. 18, the aircraft took part in a “sequenced bilateral show of force” over the Korean peninsula carrying “live” AIM-120 AMRAAM missiles in the internal weapons bays.
A U.S. Marine Corps F-35B Lightning II aircraft with Marine Fighter Attack Squadron (VMFA) 121 departs Marine Corps Air Station Iwakuni, Japan, Sept. 18, 2017. The F-35B Lightning II aircraft joined United States Air Force, Japan and Republic of Korea Air Force aircraft in a sequenced bilateral show of force over the Korean peninsula. This show-of-force mission demonstrated sequenced bilateral cooperation, which is essential to defending U.S. allies, partners and the U.S. homeland against any regional threat. Note the AIM-120 barely visible inside the weapons bay (U.S. Marine Corps photo by Cpl. Aaron Henson)
As already reported, the F-35s would be probably involved in the Phase 4 of an eventual pre-emptive air strike on Pyongyang, the phase during which tactical assets would be called to hunt road-mobile ballistic missiles and any other artillery target that North Korea could use to launch a retaliatory attack (even a nuclear one) against Seoul.
Moreover, during the opening stages of an air war, the F-35Bs would be able to act as real-time data coordinators able to correlate and disseminate information gathered from their on board sensors to other assets contributing to achieve the “Information Superiority” required to geo-locate the threats and target them effectively.
Considered that Marine aviation officials have said that up to half of the current F/A-18 Hornets are not ready for combat, the deployment to the CENTCOM AOR a key step in the long-term plan to replace the legacy F/A-18 Hornet, EA-6B Prowler, and AV-8B Harrier fleets with a total of 353 F-35Bs and 67 F-35Cs by 2032.
Touchdown imminent during “Proof of Concept” demonstration on the USS America (LHA-6) November 19, 2016. (Todd Miller)
In October 2016, a contingent of 12 F-35Bs took part in Developmental Test III aboard USS America followed by the Lightning Carrier “Proof of Concept” demonstration on the carrier on Nov. 19, 2016. During the POC, the aircraft proved it can operate at-sea, employing a wide array of weapons loadouts with the newest software variant and some of the most experienced F-35B pilots said that “the platform is performing exceptionally.” The eventual participation in a real operation such as Operation Inherent Resolve (OIR) over Syria and Iraq, albeit rather symbolic, will also be the first opportunity to assess the capabilities of the platform in real combat. As for the Israeli F-35s, the airspace over the Middle East (or Central Asia) could be a test bed for validating the tactical procedures to be used by the new aircraft in the CAS (Close Air Support) mission with added Intelligence, Surveillance & Reconnaissance (ISR) and Command & Control (C2) capability.
If committed to support OIR, the F-35B will probably operate in a “first day of war” configuration carrying weapons internally to maintain low radar cross-section and observability from sensors playing both the “combat battlefield coordinators” role, collecting, managing and distributing intelligence data, and the “kinetic attack platform” role, dropping their ordnance on the targets and passing targeting data to older 4th Gen. aircraft via Link-16. More or less what done by the USMC F-35Bs during Red Flag 17-3 earlier in 2017; but next year it will be for the real thing.
Top image credit: U.S. Marine Corps photo by Lance Cpl. Becky Calhoun
